Occurrence, types and distribution of calcium oxalate crystals in leaves and stems of some species of poisonous plants

Botanical StudiesAn International Journal201455:32

DOI: 10.1186/1999-3110-55-32

Received: 13 January 2014

Accepted: 10 March 2014

Published: 15 March 2014

Abstract

Background

Calcium oxalate crystals, which are found in many organs of plants, have different morphological forms: as druses, prism, styloids, raphides and crystal sand. In this study, the distribution, type and specific location of calcium oxalate crystals in the leaves and stems of the eight species of poisonous plants and one species of nonpoisonous plant were investigated with light microscopy. During study special attention was given to the possible correlation between the presence and types of calcium oxalate crystals and toxic plant organs. The plants examined in this study were Hedera helix L. (Araliaceae), Aristolochia clematitis L. (Aristolochiaceae), Humulus lupulus L. (Cannabaceae), Saponaria officinalis L. (Caryophyllaceae), Chelidonium majus L. (Papaveraceae), Hypericum perforatum L. (Hypericaceae), Tribulus terrestris L. (Zygophyllaceae), Cynanchum acutum L. (Asclepiadaceae), and Nerium oleander L. (Apocynaceae).

Results

Three types of crystals: druses, prismatic crystals and crystal sands were observed. Druses were identified in the leaves and stems of six species of studied plants. In contrast to druses, crystal sands and prismatic crystals were rare. Prismatic crystals were observed in the leaf mesophlly cells of both Nerium oleander and Cynanchum acutum. However, crystal sands were observed only in the pith tissue of Humulus lupulus. On the other hand, leaves and stems of Chelidonium majus, Aristolochia clematitis and Hypericum perforatum were devoid of crystals.

Conclusion

There is no absolute correlation between the presence and type of calcium oxalate crystals and toxic plant organs. However druse crystals may function as main irritant in toxic organs of the plants.

Keywords

European Turkey Poisonous plants Ca-oxalate crystals Druse crystals Crystal sands Prismatic crystals

Background

Plants containing toxic substances in amounts that can cause illness or death of humans and animals are called poisonous plants (Aplin 1976). Depending on the plant species, the poisonous parts of the plants can be the root, rhizome, bulb, stem, branch, leaf, flower, fruit, seed, pollen, nectar or sap (Seçmen and Leblebici 1987). There are several toxicologically significant plant constituents such as oxalates, alkaloids, glycosides, amino acids, proteins, minerals, acids, terpenes, phytotoxins, photosensitizing compounds, phenolics and tannins. These are generally known as secondary metabolites (Frohne and Pfander 1984). In many plants, oxalates are metabolized very slowly or not. However, they might have a toxic effect when accumulating in excess quantities (Franceschi and Horner 1980). Moreover, free calcium at high concentrations is also toxic to cells. Therefore plants could induce calcium oxalate crystal formation to remove excess oxalate or calcium (Çalışkan 2000).

Calcium oxalate crystals occur in more than 215 higher plant families (McNair 1932 Franceschi and Horner 1980; Lersten and Horner 2006) including gymnosperms and angiosperms. In angiosperms crystal formation is generally intracellular and crystals form inside the vacuoles of specialized cells called idioblast. However, in gymnosperms most of the crystals form in the cell wall (Kinzel 1989). Crystal formation in idioblasts is usually related with membranes, chambers, or inclusions found within the vacuoles. Crystal idioblasts have different shapes, sizes and intracellular structures than non-crystal- forming cells of the same tissue (Horner and Wagner 1995) and may also contain, tubules modified plastids and enlarged nuclei (Franceschi and Horner 1980). Additionally, the idioblasts undergo ultrastructural modifications depending on crystal precipitation.

Although the shape, size and number of crystals show variations among taxa, they have been classified into five main groups based on their morphology: as prism, druses, styloids, raphides and crystal sand (Webb 1999). Various physical, chemical and biological parameters such as light, temperature, pH, ion concentration and herbivory may affect the location, size and other properties of crystals in plants (Franceschi and Horner 1980; Molano-Flores 2001; Kuo-Huang et al. 2007; Meriç 2009). However, many authors have stated that crystal formation within the cell is under genetic control (Ilarslan et al. 2001). Thus the shape and location of the crystals within a taxon are often very specific and may be represented as a taxonomic character (Genua and Hillson 1985; Prychid and Rudall 1999; Lersten and Horner 2000). Furthermore, the presence or absence of crystals may represent useful taxonomic characters and also be used for understanding the evolutionary relationships of plant species (Franceschi and Horner 1980; Prychid and Rudall 1999). For example, by considering both morphological and molecular characteristics and the distribution of calcium oxalate crystals in some taxa, Rudall and Chase (1996) have shown that the genera formerly included in Xanthorrhoeaceae sensu lato may belong to three different families: Xanthorrhoeaceae sensu stricto, Lomandraceae and Dasypogonaceae (Prychid and Rudall 1999).

Calcium oxalate crystals may be present in almost all parts of the plant. Presence of calcium oxalate crystals have been reported in roots (Horner et al. 2000; Dane et al. 2000; Aybeke 2012a), leaves (Horner and Whitmoyer 1972; Doaigey 1991; Faheed et al. 2013), stems (Grimson and Arnott 1983; Meriç 2008,2009; Aybeke et al. 2010), seeds (Buttrose and Lott 1978; Lott and Buttrose 1978; Webb and Arnott 1982,1983; Ilarslan et al. 2001; Meriç 2008,2009), floral organs (Tilton and Horner 1980; Meriç and Dane 2004; Ekici and Dane 2007) and anthers (Horner and Wagner 1980;1992; Ekici and Dane 2009; Aybeke 2012b), and root nodules (Sutherland and Sprent 1984). These crystals can be located in specific tissues such as epidermis, cortex, phloem, xylem and pith or they may be distributed all over the plant.

Many functions have been attributed to calcium oxalate crystals in plants such as participating in calcium homeostasis, storage of calcium (Franceschi 1989), removal of excess oxalate, metal detoxification, tissue support, light gathering and reflection (Franceschi and Horner 1980), and protection against insects and foraging animals. Calcium oxalate crystals protect plants against herbivores by their association with irritating chemicals or with proteolytic toxins (Rupali et al. 2012). Mechanical effect of needle like crystals which puncture the foraging animals is also important part of the plant defence.

Many forage plants can accumulate oxalate in toxic concentrations (Dhillon et al. 1971; Cheeke 1995; Rahman et al. 2006). Therefore most of the oxalate-containing plants may cause poisoning to ruminants. However, susceptibility of animals to oxalate poisoning depends on factors such as chemical form of the oxalate, age of the animal, adaptation of animals to oxalate-rich forage, composition of the diet and availability of water for animals (Rahman and Kawamura 2011).

Although there have been numerous studies on calcium oxalate crystals in plants, only a few studies (Fasset 1973; Doaigey 1991) have been carried out to investigate the relationship between calcium oxalate crystals and toxicity of plants. Therefore, in the present study, types and specific locations of calcium oxalate crystals in the stems and leaves of the eight species of poisonous plant and one species of non- poisonous plant were investigated to reveal the possible relationship between calcium oxalate crystals and poisonous organs of plants. Non- poisonous plant, Humulus lupus L., was examined in order to provide a comparative demonstration of the relationship between the poisonous properties of the plants and their crystals.

The primary aim of this study was (1) to contribute to the previous studies by testing the hypothesis which suggests the relationship between the presence of calcium oxalate crystals and the toxicity of plant organs, (2) to provide data for the taxonomic and phylogenetic studies by reporting the type and specific location of calcium oxalate crystals in selected species of plants.

Methods

In this study, eight species of poisonous plants and one species of nonpoisonous plants belonging to different families were collected from natural habitats in Edirne Province (European Turkey).

Collected species were identified by Feruzan Dane. The voucher specimens were kept in the herbarium of Trakya University (EDTU). The collection data of the investigated specimens were given in Table 1.
Table 1

List of examined species and their collection data

Species

EDTU number

Collector

Date of collection

Location

Aristolochia clematitis L.

13385

Dane & Öztürk

16 July 2008

Söğütlük, Edirne

Chelidonium majus L.

13386

Dane & Öztürk

16 July 2008

Söğütlük, Edirne

Cynanchum acutum L.

13387

Dane & Öztürk

16 July 2008

Söğütlük, Edirne

Hedera helix L.

13388

Dane & Öztürk

16 July 2008

Söğütlük, Edirne

Humulus lupulus L.

13389

Dane & Öztürk

15 July 2008

Söğütlük, Edirne

Hypericum perforatum L.

13390

Dane & Öztürk

15 July 2008

Söğütlük, Edirne

Nerium oleander L.

13391

Dane & Öztürk

18 July 2008

Söğütlük, Edirne

Saponaria officinalis L.

13392

Dane & Öztürk

16 July 2008

Söğütlük, Edirne

Tribulus terrestris L.

13393

Dane & Öztürk

18 July 2008

Centre, Edirne

At least five leaf and stem samples were collected from each species in the budding season, and they were fixed in carnoy fluid (3:1 v/v, ethyl alcohol: acetic acid) at room temperature overnight and transferred to 70% ethyl alcohol. For light microscopy study, cross sections were obtained by hand from fixed samples and sections were treated with a solution of 2.5% sodium hypo chloride (bleaching agent) for 4 hours (Ilarslan et al. 2001). The cleared samples were covered with glycerine-gelatine to form a permanent preparation. Sections were examined under light photomicroscope (Olympus) with bright and polarized light, and the types and locations of the crystals were determined. Moreover, diameters of the druse crystals were measured using Image-Pro Plus program, and averages and standard deviations of data were calculated. Photomicrographs were taken with an Olympus digital camera and processed in Adobe PhotoShop CS2 version 9.

Results

In the present study, six of the nine examined plants were found to contain calcium oxalate crystals. Types of crystals found in the leaves and stems of examined plants were given in Table 2. Three types of calcium oxalate crystals were observed: druses, prismatic crystals and crystal sands. Types and distribution of crystals in each of the studied plant are described in details below.
Table 2

Comparison of the types of calcium oxalate crystals and content of the toxic substance found in plant organs

Species

Types of crystals in leaves

Types of crystals in stems

Content of toxic substances

Poisonous organs

Cynanchum acutum L.

Druse and prismatic

Druse

Vincetoksin glycoside (Öztürk et al. 2008)

Entire plant (Öztürk et al. 2008)

Tribulus terrestris L.

Druse

Druse

Three sapogenins (Diosgenin, ruscogenin, gitogenin) (Fuller and McClintock 1986)

Entire Plant (Fuller and McClintock 1986)

Hedera helix L.

Druse

Druse

Hederin glycoside, Hederagenin, and other triterpene saponins, sesquiterpenes, falcarinol (Fuller and McClintock 1986; Wink 2009)

Entire plant, especially leaves and fruits (Wink 2009)

Saponaria officinalis L.

Druse

Druse

Saponin Glycoside (triterpene saponins) (Wink 2009)

Entire plant especially seeds (Muca et al. 2012)

Humulus lupulus L.

Druse

Druses and Crystal sands

Non poisonous (Baytop 1999)

Non poisonous (Baytop 1999)

Nerium oleander L.

Druse

Druse and Prismatic

Oleandrin glycoside and several other cardenolides (Wink 2009)

Entire plant (Wink 2009)

Hypericum perforatum L.

Absent

Absent

Hypericin , Glyco-Alkaloid (Fuller and McClintock 1986)

Entire plant, especially leaves and flowers (Fuller and McClintock 1986)

Aristolochia clematitis L.

Absent

Absent

Aristolochic acid and related alkaloids, aristolohin alkaloid magnoflorine (Wink 2009)

Entire plant (Wink 2009)

Chelidonium majus L.

Absent

Absent

Chelidonine, sanguinarine, berberine and other isoquinoline alkaloids (Wink 2009)

All parts (Wink 2009)

Cynanchum acutum L.

Druse crystals were observed in the stem and leaves of Cynanchum acutum. They were numerous in the stem cortex (12.5 ± 1.93 μm in diameter) of the Cynanchum acutum, but were scarce in its leaves (Figure 1). In the leaves, druse crystals were distributed either around the midrib or along the minor veins near xylem vessels. Around major vein, druse crystals in different sizes (9.5 ± 2.2 μm in diameter) were in clusters (Figure 1E). However, along minor veins a few small druse crystals (8 μm in diameter) and prismatic crystals having conspicuous cores were observed (Figure 1F).
https://static-content.springer.com/image/art%3A10.1186%2F1999-3110-55-32/MediaObjects/40529_2014_Article_88_Fig1_HTML.jpg
Figure 1

Calcium oxalate crystals in the stem and leaf of Cynanchum acutum . (A-C) Druse crystals in the cortex of the stem at different magnifications. (D) Druse crystals in the leaf mesophyll. (E) Druse crystals around the major vein. (F) Druse and prismatic crystals along vascular bundle. (Dc: Druse crystals; Pc: Prismatic crystals).

Tribulus terrestris L.

In Tribulus terrestris, druse crystals were sparsely distributed in the mesophyll tissue of the leaf (24.5 ± 3 μm in diameter) and in the cortex tissue (22.2 ± 4 μm in diameter) of the stem (Figure 2).
https://static-content.springer.com/image/art%3A10.1186%2F1999-3110-55-32/MediaObjects/40529_2014_Article_88_Fig2_HTML.jpg
Figure 2

Druse crystals in the stem and leaf of Tribulus terrestris. (A, B) Druse crystals in the cortex of the stem. (C, D) Druse crystal in the leaf mesophyll cells. (Dc: Druse crystals).

Hedera helix L.

Druse crystals were identified in the stem and leaves of Hedera helix (Figure 3). In the stem, druse crystals were observed both in the cortex and pith tissues (Figure 3A-C). In the cortex tissue, moderate number of druse crystals (20.6 ± 1.5 μm in diameter) were dispersed either singly or in groups of two or three. However, in pith tissue druse crystals (17.1 ± 5 μm in diameter) were rare.
https://static-content.springer.com/image/art%3A10.1186%2F1999-3110-55-32/MediaObjects/40529_2014_Article_88_Fig3_HTML.jpg
Figure 3

Druse crystals in the stem and leaf of Hedera helix (arrow). (A) Druse crystals in the cortex and pith cells of the stem. (B) Druse crystals in the pith cells of the stem. (C) Druse crystal in the cortex cells of the stem. (D-F) Distribution of druse crystals in leaf mesophyll cells. (Dc: Druse crystals).

In the leaf, druse crystals (16.2 ± 3.9 μm in diameter) were observed both in the mesophyll tissue and around the vascular bundles (Figure 3D-F). In the mesophyll tissue, they were densely distributed in the spongy tissue. However, only a few druse crystals were present in the palisade tissue. About 9–10 crystals which arranged in one row of cells were observed along some regions of minor veins. Additionally, some of the druse crystals were in contact with the xylem or phloem vessels.

Saponaria officinalis L.

A few druse crystals were observed in the pith tissue of the stem (26 ± 1.2 μm in diameter) and mesophyll tissue of the leaf (Figure 4). In the leaf, druse crystals of different sizes (22 ± 4.2 μm in diameter) were distributed rarely in the spongy mesophyll.
https://static-content.springer.com/image/art%3A10.1186%2F1999-3110-55-32/MediaObjects/40529_2014_Article_88_Fig4_HTML.jpg
Figure 4

Druse crystals in the stem and leaf cross sections of Saponaria officinalis . (A, B) Druse crystals in the pith cells of the stem. (C, D) Distribution of the druse crystals in leaf mesophyll cells. (Dc: Druse crystals).

Humulus lupulus L.

A few druse crystals (16.6 ± 1 μm in diameter) and crystal sands were identified in the pith tissue of the stem of Humulus lupulus (Figure 5A, B). In the leaves, druse crystals were located both around the vascular tissue and in the palisade and spongy tissue of the mesophyll (Figure 5C, D). In the mesophyll tissue, druses were rare and their diameters changed between 12.5 – 16.4 μm (14.3 ± 2 μm). However, around vascular bundle, a cluster of druse crystals at various sizes (11–20 μm in diameter) was observed (Figure 5D). Druse crystals that were located near the vascular bundle were smaller than the others.
https://static-content.springer.com/image/art%3A10.1186%2F1999-3110-55-32/MediaObjects/40529_2014_Article_88_Fig5_HTML.jpg
Figure 5

Druse crystals in the stem and leaf cross sections of Humulus lupulus . (A) Druse crystals in the pith cells of the stem. (B) Druses and crystal sands in the pith cells of the stem. (C) Druse crystal in leaf mesophyll cells. (D) Druse crystals around the vascular bundle (Dc: Druse crystals; Cs: Crystal sands).

Nerium oleander L.

In Nerium oleander, numerous single druse crystals were identified in the cortex (17.5 ± 2.86 μm in diameter) and pith tissues (18.5 ± 2.5 μm in diameter) of the stem (Figure 6A, B). In the leaves, druse crystals were observed both around the major vein (19.1 ± 2.8 μm in diameter) and in the mesophyll tissue (22.6 ± 6 μm in diameter). In the mesophyll tissue, druse crystals were distributed either singly or 3–4 crystals were arranged in one row of cells (Figure 6D). In addition to druses, a few prismatic crystals were also observed in the cortex tissue of the stem (Figure 6C) and leaf mesophyll cells of Nerium oleander (Figure 6F).
https://static-content.springer.com/image/art%3A10.1186%2F1999-3110-55-32/MediaObjects/40529_2014_Article_88_Fig6_HTML.jpg
Figure 6

Crystals in the stem and leaf cross-sections of Nerium oleander . (A, B) Druse crystals in the cortex of the stem, (C) Druse and prismatic crystals in the cortex of the stem, (D) Druse crystals in leaf mesophyll cells, (E) Druse crystals around the midrib, (F) Prismatic crystals in leaf mesophyll cells. (Dc: Druse crystals; Pc: Prismatic crystals).

No crystals were observed in the leaves and stems of Aristolochia clematitis, Chelidonium majus and Hypericum perforatum.

Discussion and conclusion

Although numerous studies have been made on calcium oxalate crystals, only a few of them (Fasset 1973 Genua and Hillson 1985 Doaigey 1991) have investigated the calcium oxalate crystals in toxic plant organs. Genua and Hillson (1985), in their study of oxalate crystals in toxic plant organs, concluded that although the relationship between druses and the poisonous properties of the plant was not fully known, druses may be the main mechanical irritants in toxic plants. Besides this, Doaigey (1991) has tried to correlate toxic parts of the plant with the distribution of calcium oxalate crystals; however, he has concluded that there is no absolute relationship between calcium oxalate crystals and the poisonous properties of the plants.

In the present study, Humulus lupulus which was reported as non-toxic (Baytop 1999) examined as a reference and it was found that it contains druse crystals in the mesophyll cells of its leaves and druses and crystal sands in the pith cells of its stem. Wu and Kuo-Huang (1997) have studied calcium crystals in the leaves of Humulus scandens and they have reported only calcium carbonate crystals in its leaves. The differences in the types of calcium crystals between these two different species of the genus Humulus is not surprising. Because, although crystal formation in plants is mostly under genetic control (Ilarslan et al. 2001), the location, size and other properties of crystals may be effected by physical, chemical and biological conditions such as light, temperature, pH, ion concentration and herbivory (Franceschi and Horner 1980; Molano-Flores 2001; Kuo-Huang et al. 2007). Moreover, features of calcium crystals in the leaves of Humulu s may be useful in intra genus classification.

The stem and leaves of Cynanchum acutum and Hedera helix were reported as poisonous (Fuller and McClintock 1986) and were found to have druse crystals. The whole of Hypericum perforatum (Baytop 1963,1989; Fuller and McClintock 1986), Nerium oleander (Baytop 1989; Wink 2009; Muca et al. 2012), Tribulus terrestris (Fuller and McClintock 1986), Saponaria officinalis (Muca et al. 2012), Aristolochia clematitis (Wink 2009) and Chelidonium majus (Wink 2009) display toxic properties but only stem and leaves of Nerium oleander have druses and prismatic crystals. Additionally, druses have been observed both in the stem and leaves of Tribulus terrestris and Saponaria officinalis. On the other hand, calcium oxalate crystals were not identified in the stem and leaves of Aristolochia clematitis, Chelidonium majus and Hypericum perforatum (Table 2).

In the present study, although druse crystals have been observed both in the stem and leaves of Saponaria officinalis, in the study of Ataşlar (2004) on Saponaria kotschyi Boiss, druses have been reported only in the leaves and roots of Saponaria kotschyi but not in the stem. So this supports the idea that location of the crystals within a taxon is often very specific and may be represented as a taxonomic character (Genua and Hillson 1985; Prychid and Rudall 1999; Lersten and Horner 2000).

In Nerium oleander druse and prismatic crystals were observed in the adjacent cells of the cortex tissue of the stem. This confirms the idea of Scurfield et al. (1973) which suggested that impurities which would most likely differ from cell to cell, may lead to the formation of different crystal types in the same tissue. However, this result appears to be inconsistent with the fact that some plants contain only one type of crystal through the many tissues (Franceschi and Horner 1980). Similar to our results, Doaigey (1991) have also reported druses and prismatic crystals in the leaves and stem of Nerium oleander growing naturally in Saudi Arabia.

Poisonous compounds in the studied species are either alkaloids or glycosides. Five of the eight poisonous plant species contain glycosidic compounds, and have druse crystals. However, three of the studied plants have alkaloids as poisonous compounds, and all of them are devoid of calcium oxalate crystals (Table 2). Therefore, the results of the present study point out the correlation between the kinds of toxic substance and the presence of calcium oxalate crystals in the studied plants. However, in the study of Doaigey (1991), investigating calcium oxalate crystals in the sixteen species of poisonous plants, calcium oxalate crystals have been reported in the four of the seven species having alkaloids and in the three of the seven species containing glycosidic compounds. The results of the Doaigey’s study don’t confirm the findings of our study related with alkaloids and glycosides. Consequently there is no sufficient evidence to prove the relationship between the kind of toxic substances and occurrence, types and distribution of calcium oxalate crystals in plant organs.

In the light of the results, collected data and literature survey it can be concluded that there is no absolute correlation between the presence of calcium oxalate crystals and the toxicity of plant organs. This conclusion confirms the results of the studies which are carried out by Genua and Hillson (1985), and Doaigey (1991). Furthermore, druses are the most abundant calcium oxalate crystals in poisonous organs of the studied plants. Hence, as stated by Genua and Hillson (1985) druses may function as main mechanical irritants in toxic plants.

Declarations

Acknowledgments

We would like to thank the Scientific Research Fund of Trakya University, which financially supported this study.

Authors’ Affiliations

(1)
Faculty of Science, Department of Biology, Trakya University

References

  1. Aplin TEH: Poisonous Garden Plants and Other Plants Harmful to Man in Australia. Bulletin 3964. Department of Agriculture, Perth, WA; 1976:58.Google Scholar
  2. Ataşlar E: Morphological and anatomical investigations on the Saponaria kotschyi Boiss. (Caryophyllaceae). Turk J Bot 2004, 28: 193–199.Google Scholar
  3. Aybeke M: Comparative anatomy of selected rhizomatous and tuberous taxa of subfamilies Orchidoideae and Epidendroideae (Orchidaceae) as an aid to identification. Plant Syst Evol 2012a, 298(9):1643–1658.View ArticleGoogle Scholar
  4. Aybeke M: Anther wall and pollen development in Ophrys mammosa L. (Orchidaceae). Plant Syst Evol 2012b, 298: 1015–1023.View ArticleGoogle Scholar
  5. Aybeke M, Sezik E, Olgun G: Vegetative anatomy of some Ophrys , Orchis and Dactylorhiza (Orchidaceae) taxa in Trakya region of Turkey. Flora 2010, 205(2):73–89.View ArticleGoogle Scholar
  6. Baytop T: Türkiye’nin tıbbi ve zehirli bitkileri. İsmail Akgün matbası, İstanbul; 1963.Google Scholar
  7. Baytop T: Türkiye’de zehirli bitkiler, bitki zehirlenmeleri ve tedavi yöntemleri. İ.Ü. Ecz. Fak. Yay No: 54, İstanbul; 1989.Google Scholar
  8. Baytop T: Türkiye’de tıbbi bitkiler ile tedavi. Nobel,İstanbul; 1999.Google Scholar
  9. Buttrose MS, Lott JNA: Calcium oxalate druse crystals and other inclusions in seed protein bodies: Eucalyptus and jojoba. Can J Bot 1978, 56: 2083–2091.View ArticleGoogle Scholar
  10. Çalışkan M: The metabolism of oxalic acid. Turk J Zool 2000, 24: 103–106.Google Scholar
  11. Cheeke PR: Endogenous toxins and mycotoxins in forage grasses and their effects on livestock. J Anim Sci 1995, 73: 909–918.PubMedGoogle Scholar
  12. Dane F, Hüseyinova G, Meriç Ç: Some ultrastructural observation on calcium oxalate raphide crystal idioblasts and meristematic cells of the adventive root tip of Sternbergia lutea (L.) Ker- Gawl. Ex Sprengel (Amaryllidaceae). Turk J Bot 2000, 24: 71–80.Google Scholar
  13. Dhillon KS, Paul BS, Bajwa RS, Singh J: A preliminary report on a peculiar type of napiergrass ( Pennisetum purpureum , 'Pusa giant’) poisoning in buffalo calves. Indian J Anim Sci 1971, 41: 1034–1036.Google Scholar
  14. Doaigey AR: Occurrence, type, and location of calcium oxalate crystal in leaves and stems of 16 species of poisonous plants. Am J Bot 1991, 78: 1608–1616.View ArticleGoogle Scholar
  15. Ekici N, Dane F: Calcium oxalate crystals in floral organs of Galanthus sp. (Amaryllidaceae). Asian J Plant Sci 2007, 6(3):508–512.View ArticleGoogle Scholar
  16. Ekici N, Dane F: Calcium oxalate crystals during development of male and female gametophyte in Leucojum aestivum (Amaryllidaceae). Jabs 2009, 3(1):15–18.Google Scholar
  17. Faheed F, Mazen A, Abd Elmohsen S: Physiological and ultrastructural studies on calcium oxalate crystal formation in some plants. Turk J Bot 2013, 37: 139–152.Google Scholar
  18. Fasset DW: Oxalates. In Toxicants Occurring Naturally in Foods. National Academy of sciences, Washington DC; 1973:342–362.Google Scholar
  19. Franceschi VR: Calcium oxalate formation is a rapid and reversible process in Lemna minor . Protoplasma 1989, 148: 130–137.View ArticleGoogle Scholar
  20. Franceschi VR, Horner HT Jr: Calcium oxalate crystals in plants. Bot Rev 1980, 46: 361–427.View ArticleGoogle Scholar
  21. Frohne D, Pfander J: A Colour Atlas of Poisonous Plants. Wolfe, London; 1984.Google Scholar
  22. Fuller TC, McClintock E: Poisonous Plants of California. University of California Press, Berkeley, CA; 1986.Google Scholar
  23. Genua JM, Hillson CJ: The occurrence, type and location of calcium oxalate crystals in the leaves of fourteen species of Araceae. Ann Bot 1985, 56: 351–361.Google Scholar
  24. Grimson MJ, Arnott HJ: An ultrastructural study of druse crystals in the abscission zone of Phyllanthus niruri L. Scan Electron Microsc 1983, 4: 1771–1778.Google Scholar
  25. Horner HT Jr, Wagner BL: The association of druse crystals with the developing stomium of Capsicum annuum (Solanaceae) anthers. Am J Bot 1980, 67: 1347–1360.View ArticleGoogle Scholar
  26. Horner HT, Wagner BL: Association of four different calcium crystals in the anther connective tissue and hypodermal stomium of Capsicum annuum (Solanaceae) during microsporogenesis. Am J Bot 1992, 79: 531–541.View ArticleGoogle Scholar
  27. Horner HT, Wagner BL: Calcium oxalate formation in higher plants. In Calcium oxalate in biological systems. Edited by: Khan SR. CRC, Boca Raton, Florida; 1995:53–72.Google Scholar
  28. Horner HT, Whitmoyer RE: Raphide crystal cell development in leaves of Psychotria punctata (Rubiaceae). J Cell Sci 1972, 11: 339–355.PubMedGoogle Scholar
  29. Horner HT, Kausch AP, Wagner BL: Ascorbic acid: a precursor of oxalate in crystal idioblasts of Yucca torrey in liquid root culture. Int J Plant Sci 2000, 161: 861–868.View ArticleGoogle Scholar
  30. Ilarslan H, Palmer RG, Horner HT: Calcium oxalate crystals in developing seeds of soybean. Ann Bot 2001, 88: 243–257.View ArticleGoogle Scholar
  31. Kinzel H: Calcium in the vacuoles and cell walls of plant tissues. Flora 1989, 182: 99–125.Google Scholar
  32. Kuo-Huang LL, Ku MSB, Franceschi VR: Correlations between calcium oxalate crystals and photosynthetic activities in palisade cells of shade-adapted Peperomia glabella . Bot Stud 2007, 48: 155–164.Google Scholar
  33. Lersten NR, Horner HT: Calcium oxalate crystals types and trends in their distribution patterns in leaves of Prunus (Rosaceae: Prunoideae). Plant Syst Evol 2000, 224: 83–96.View ArticleGoogle Scholar
  34. Lersten NR, Horner HT: Crystal macropattern development in Prunus serotina ( Rosaceae, Prunoideae) leaves. Ann Bot 2006, 97: 723–729.View ArticlePubMedPubMed CentralGoogle Scholar
  35. Lott JNA, Buttrose MS: Location of reserves of mineral elements in seed protein bodies: macadamia nut, walnut, and hazel nut. Can J Bot 1978, 56: 2072–2082.View ArticleGoogle Scholar
  36. McNair JB: The intersection between substances in plants: essential oils and resins, cyanogen and oxalate. Am J Bot 1932, 19: 255–271.View ArticleGoogle Scholar
  37. Meriç Ç: Calcium oxalate crystals in Conyza canadensis (L.) Cronq. and Conyza b onariensis (L.) Cronq. (Asteraceae: Astereae). Acta Biol Szeged 2008, 52: 295–299.Google Scholar
  38. Meriç Ç: Calcium oxalate crystals in some species of the Tribe Inuleae (Asteraceae). Acta Biol Cracov Ser Bot 2009, 51: 105–110.Google Scholar
  39. Meriç Ç, Dane F: Calcium oxalate crystals in floral organs of Helianthus annuus L. and tuberosus L. (Asteraceae). Acta Biol Szeged 2004, 48(1–4):19–23.Google Scholar
  40. Molano-Flores B: Herbivory and calcium concentrations affect calcium oxalate crystal formation in leaves of Sida (Malvaceae). Ann Bot 2001, 88: 387–391.View ArticleGoogle Scholar
  41. Muca B, Yıldırım B, Özçelik Ş, Koca A: Isparta’s (Turkey) poisonous plants of public access places. BioDiCon 2012, 5(1):23–30.Google Scholar
  42. Öztürk M, Uysal İ, Gücel S, Mert T, Akçiçek E, Sezgin Ç: Ethnoecology of poisonous plants of Turkey and Northern Cyprus. Pak J Bot 2008, 40(4):1359–1386.Google Scholar
  43. Prychid CJ, Rudall PJ: Calcium oxalate crystals in monocotyledons: a review of their structure and systematics. Ann Bot 1999, 84: 725–739.View ArticleGoogle Scholar
  44. Rahman MM, Kawamura O: Oxalate accumulation in forage plants: some agronomic, climatic and genetic aspects. Asian Aust J Anim Sci 2011, 24(3):439–448.View ArticleGoogle Scholar
  45. Rahman MM, Niimi YI, Kawamura O: Effects of seasons, variety and botanical fractions on oxalate content of napiergrass ( Pennisetum purpureum Schumach). Grassl Sci 2006, 52: 161–166.View ArticleGoogle Scholar
  46. Rudall PJ, Chase MW: Systematics of Xanthorrhoeaceae sensu lato : evidence for polyphyly. Telopea 1996, 6: 629–647.View ArticleGoogle Scholar
  47. Rupali T, Chavan S, Pandhure N: Occurrence of chloride enriched calcium oxalate crystal in cissus quadrangularis linn. Int J Pharm 2012, 2(2):337–340.Google Scholar
  48. Scurfield G, Michell AJ, Silva SR: Crystals in woody stems. Bot J Linn Soc 1973, 66: 277–289.View ArticleGoogle Scholar
  49. Seçmen O, Leblebici E: Yurdumuzun Zehirli Bitkileri. Ege Üniversitesi Fen Fakültesi Kitaplar Serisi Yay No: 103, İzmir; 1987.Google Scholar
  50. Sutherland JM, Sprent JI: Calcium-oxalate crystals and crystal cells in determinate root nodules of legumes. Planta 1984, 161: 193–200.View ArticlePubMedGoogle Scholar
  51. Tilton VR, Horner HT Jr: Calcium oxalate raphide crystals and crystalliferous idioblasts in the carpels of Ornithogalum caudatum . Ann Bot 1980, 46: 533–539.Google Scholar
  52. Webb MA: Cell-mediated crystallization of calcium oxalate in plants. Plant Cell 1999, 11: 751–761.View ArticlePubMedPubMed CentralGoogle Scholar
  53. Webb MA, Arnott HJ: A survey of calcium oxalate crystals and other mineral inclusions in seeds. Scan Electron Micros 1982, 3: 1109–1131.Google Scholar
  54. Webb MA, Arnott HJ: Inside plant crystals: a study of the noncrystalline core in druses of Vitis vinifera endosperm. Scan Electron Micros 1983, 4: 1759–1770.Google Scholar
  55. Wink M: Mode of action and toxicology of plant toxins and poisonous plants. Julius Kühn-Inst, Mitt; 2009:421.Google Scholar
  56. Wu CC, Kuo-Huang LL: Calcium crystals in the leaves of some species of Moraceae. Bot Bull Acad Sin 1997, 38: 97–104.Google Scholar

Copyright

© Tütüncü Konyar et al.; licensee Springer. 2014

This article is published under license to BioMed Central Ltd. This is an Open Access article distributed under the terms of the Creative Commons Attribution License (http://creativecommons.org/licenses/by/2.0), which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly credited.
