Identification among morphologically similar Argyreia (Convolvulaceae) based on leaf anatomy and phenetic analyses

  • Paweena Traiperm1Email author,
  • Janene Chow1, 2,
  • Possathorn Nopun1, 2,
  • G. Staples3 and
  • Sasivimon C. Swangpol1
Botanical StudiesAn International Journal201758:25

DOI: 10.1186/s40529-017-0178-6

Received: 14 April 2017

Accepted: 23 May 2017

Published: 2 June 2017

Abstract

Background

The genus Argyreia Lour. is one of the species-rich Asian genera in the family Convolvulaceae. Several species complexes were recognized in which taxon delimitation was imprecise, especially when examining herbarium materials without fully developed open flowers. The main goal of this study is to investigate and describe leaf anatomy for some morphologically similar Argyreia using epidermal peeling, leaf and petiole transverse sections, and scanning electron microscopy. Phenetic analyses including cluster analysis and principal component analysis were used to investigate the similarity of these morpho-types.

Results

Anatomical differences observed between the morpho-types include epidermal cell walls and the trichome types on the leaf epidermis. Additional differences in the leaf and petiole transverse sections include the epidermal cell shape of the adaxial leaf blade, the leaf margins, and the petiole transverse sectional outline. The phenogram from cluster analysis using the UPGMA method represented four groups with an R value of 0.87. Moreover, the important quantitative and qualitative leaf anatomical traits of the four groups were confirmed by the principal component analysis of the first two components. The results from phenetic analyses confirmed the anatomical differentiation between the morpho-types.

Conclusions

Leaf anatomical features regarded as particularly informative for morpho-type differentiation can be used to supplement macro morphological identification.

Keywords

Leaf epidermis Leaf transverse section PCA SEM Species complex Stomatal index UPGMA

Background

The genus Argyreia Lour., one of the larger genera in Convolvulaceae with approximately 135 species, is mainly distributed in tropical Asia (Staples and Traiperm 2017). During preparation of a nomenclatural review of the genus, we found that some species of Argyreia are quite similar in their vegetative morphology leading to confusion in identification when only leaf and stem characters are available. Species delimitation in Convolvulaceae generally, including Argyreia, is heavily dependent on floral characters; when fully developed flowers are lacking it can be difficult or impossible to identify species precisely. Thus, when specimens with only leaves, or young flower buds, or fruits are all that is available it may not be possible to do more than narrow down the identification to a group of similar species. We have identified several such cases; these seem to represent species-complexes of morphologically similar species, or perhaps single highly polymorphic species. One such group of species includes Argyreia breviscapa (Kerr) Ooststr., Argyreia kerrii Craib, Argyreia suddeeana Traiperm & Staples, Argyreia variabilis Traiperm & Staples and two unnamed Argyreia that appear morphologically distinct. Previously we pointed out that some species complexes have similar macro morphological leaf characters (Staples and Traiperm 2008; Traiperm and Staples 2014). In order to explore other characters that might be useful for identification, this research investigates foliar micromorphology as a means to identify plants or specimens that lack flowers.

Leaf anatomy of some species in Argyreia had been investigated by Metcalfe and Chalk (1950), Sayeedud-Din (1953) and Pant and Bhatnagar (1975). Leaf epidermis and stem transverse sections of four Argyreia species [Argyreia nervosa (Burm.f.) Bojer, Argyreia onilahiensis Deroin, Argyreia sericea Dalzell & A. Gibson and Argyreia splendens (Hornem.) Sweet] were studied by Tayade and Patil (2003, 2012a). A key to species was constructed based on the epidermal characters such as cuticular striations, anticlinal cell walls, and basal cells of trichomes (Tayade and Patil 2003). Recent publication of a new species of Argyreia suggested that leaf epidermal characters, such as the pattern of cutin, can be used to distinguish Argyreia albiflora Staples & Traiperm from the morphologically similar species Argyreia wallichii Choisy (Staples et al. 2015). Anatomical characters strongly supported species identification in an investigation of Merremia section Xanthips (Pisuttimarn et al. 2013).

Anatomical information has been used for this analysis because it has proven useful and informative in assisting with taxonomic identification and classification in other plants (Thadeo et al. 2014). Leaf anatomical characters from several families also revealed similarities between plant species when using phenetic analysis [cluster analysis (CA) and principal component analysis (PCA)] (Nikolić and Mitić 1991; Breitwieser and Ward 1993; De Faria et al. 2010; Aghababaeyan et al. 2014; Moraes et al. 2011; Thadeo et al. 2014; Arthan et al. 2016; Jayarathna et al. 2016). In Convolvulaceae, particularly the genus Argyreia, phenetic analysis based on leaf anatomy has not been done before. The aim of this research was to study the leaf anatomy of A. breviscapa and similar-looking morpho-types and to conduct phenetic analyses using leaf anatomical characters to determine their utility for taxon discrimination and identification.

Methods

Plant collections

Plant materials were collected from their natural habitats for six morpho-types that are similar to A. breviscapa (e.g., A. kerrii, A. suddeeana, A. variabilis, Argyreia 1 and Argyreia 2). For each morpho-type, 1–5 populations were sampled. At least five mature leaves in each population were fixed in a mixture of 70% ethyl alcohol and 0.05% glycerol. Voucher specimens were prepared for each morpho-type and deposited at BKF (Table 1). Investigation of the micro-morphological characters was divided into three parts: epidermal surfaces examined by the peeling method; epidermal surfaces viewed with scanning electron microscopy (SEM); and leaf transverse sections prepared by modified paraffin method (Johansen 1940).
Table 1

List of the plant materials used in this study

No. of accession

Taxa

Voucher specimens

Locality

1

Argyreia breviscapa (Kerr) Ooststr.

J. Chow and P. Traiperm s.n.

Khon Kaen, Thailand

2

Staples et al. 1550

Kanchanaburi, Thailand

3

A. kerrii Craib

J. Chow and P. Traiperm 002

Chiang Mai, Thailand

4

A. suddeeana Staples & Traiperm

J. Chow and P. Traiperm 017

Ratchaburi, Thailand

5

J. Chow and P. Traiperm 019

Ratchaburi, Thailand

6

A. variabilis Traiperm & Staples

S. Suddee s.n.

Phetchaburi, Thailand

7

J. Chow and P. Traiperm s.n.

Phetchaburi, Thailand

8

Argyreia 1

J. Chow and P. Traiperm 030

Kanchanaburi, Thailand

9

Argyreia 2

J. Chow and P. Traiperm 031

Kanchanaburi, Thailand

10

J. Chow and P. Traiperm 032

Kanchanaburi, Thailand

11

J. Chow and P. Traiperm 033

Kanchanaburi, Thailand

12

J. Chow and P. Traiperm 034

Kanchanaburi, Thailand

13

J. Chow and P. Traiperm 035

Kanchanaburi, Thailand

Leaf epidermal surfaces

Mature leaves were selected and peeled by a razor blade. The epidermis was stained with Safranin-O for 10‒15 min, and then dehydrated in an ethyl alcohol series, finally mounted with DePeX for a permanent slide. The stomatal index was calculated according to the method described by Salisbury (1927).

Leaf surfaces were also studied intensively by the scanning electron microscope (SEM). Small pieces of leaf (5 × 5 mm2) were dehydrated in ethanol series and sonicated to remove unwanted parts from the surfaces. After that, dried samples were coated with platinum-palladium in a sputter coater (Hitachi E-102 Ion Sputter). The cuticular patterns were observed and imaged under a Hitachi S-2500 scanning electron microscope.

Leaf transverse section

The paraffin method used in this study was modified from Johansen (1940). Leaf samples were cut using a sliding microtome, stained with Safranin-O and counterstained with Fast Green. The tissues were dehydrated using ethanol series and mounted with DePeX.

The leaf characters from the epidermis and the transverse sections were observed using a light microscope, Olympus BX43, and photo-micrographed using an Olympus DP21 camera.

Phenetic analyses

Thirteen accessions (Table 1) were used in the analysis. Twenty-four leaf anatomical characters (six qualitative and 18 quantitative) were analyzed from leaf surfaces, leaf and petiole transverse sections (Table 2). The qualitative traits were repeatedly observed under light microscopy with five different leaf sample slides per one accession to confirm character stability. For the quantitative characters, each character was measured and means with standard deviations were calculated in ten replicates. For reducing bias in quantitative characters, most of them were expressed in terms of ratios (except blade thickness).
Table 2

The leaf anatomical characters and character states used in phenetic analyses

Anatomical characters

Character states

Score

Qualitative characters

 1. Epidermal cell wall on adaxial leaf surface

Straight to slightly curved/sinuate

0/1

 2. Epidermal cell wall on abaxial leaf surface

Straight to slightly curved/sinuate

0/1

 3. Types of non-glandular trichome on abaxial leaf surface

Large and small straight trichome/large straight and small curly trichome

0/1

 4. Shape of petiole

Slightly concave/convex

0/1

 5. Midrib outline and adaxial curvature

Rounded/acute

0/1

 6. Leaf margin shape

Rounded/acute

0/1

Quantitative characters

 7. Ratio of adaxial leaf epidermal cell size (width: length)

Ratio is less than or equal to 0.7/ratio is more than 0.7

0/1

 8. Stomatal index (SI) on adaxial leaf surface

SI is less than or equal to 6/SI is more than 6

0/1

 9. Ratio of stomatal size on adaxial leaf surface (width: length)

Ratio is less than or equal to 0.6/ratio is more than 0.6

0/1

 10. Ratio of glandular trichome size on adaxial leaf surface (width: length)

Ratio is less than or equal to 0.92/ratio is more than 0.92

0/1

 11. Ratio of non-glandular trichome size on adaxial leaf surface (width: length)

Ratio is less than or equal to 0.08/ratio is more than 0.08

0/1

 12. Ratio of abaxial leaf epidermal cell size (width: length)

Ratio is less than or equal to 0.65/ratio is more than 0.65

0/1

 13. Stomatal index (SI) on abaxial leaf surface

SI is less than or equal to 15/SI is more than 15, but less than or equal to 30/SI is more than 30

0/1/2

 14. Ratio of stomatal size on abaxial leaf surface (width: length)

Ratio is less than or equal to 0.75/ratio is more than 0.75

0/1

 15. Ratio of glandular trichome size on abaxial leaf surface (width: length)

Ratio is less than or equal to 0.9/ratio is more than 0.9

0/1

 16. Ratio of non-glandular trichome size on abaxial leaf surface (width: length)

Ratio is less than or equal to 0.03/ratio is more than 0.03, but less than or equal to 0.04/ratio is more than 0.04

0/1/2

 17. Ratio of epidermal cells size in petiole (width: length)

Ratio is less than or equal to 0.7/ratio is more than 0.7

0/1

 18. Ratio of petiole transverse section (width: length)

Ratio is less than or equal to 0.82/ratio is more than 0.82, but less than or equal to 0.95/ratio is more than 0.95

0/1/2

 19. Ratio of palisade mesophyll cell size in leaf transverse section (width: length)

Ratio is less than or equal to 0.2/ratio is more than 0.2

0/1

 20. Ratio of spongy mesophyll cell size in leaf transverse section (width: length)

Ratio is less than or equal to 0.7/ratio is more than 0.7

0/1

 21. Ratio of adaxial epidermal cell size in leaf transverse section (width: length)

Ratio is less than or equal to 0.7/ratio is more than 0.7

0/1

 22. Ratio of abaxial epidermal cell size in leaf transverse section (width: length)

Ratio is less than or equal to 0.7/ratio is more than 0.7

0/1

 23. Blade thickness (µm)

Thickness is less than or equal to 208/thickness is more than 208, but less than or equal to 248/thickness is more than 248

0/1/2

 24. Ratio of midrib thickness (width: length)

Ratio is less than or equal to 1/ratio is more than 1

0/1

All data were transformed into discrete numbers to score and form the data matrix. The phenetic analyses including CA and PCA were performed. The cluster analysis was conducted based on Unweighted Pair Group Method with Arithmetic Mean (UPGMA) clustering in NTSYS-pc version 2.1 (Rohlf 2000). The similarity between morpho-types resulted in phenogram was estimated by simple matching coefficient (SM). The PCA was performed using Minitab version 16 (2010). The first and second components from PCA were presented for identification of the important anatomical traits.

Results

Epidermal cell wall and cuticle

The patterns of anticlinal cell walls as seen under light microscopy appear straight to slightly curved and sinuate (Table 3). Almost all morpho-types have straight to slightly curved cell walls on adaxial surfaces, except in Argyreia 1, which shows a sinuate pattern of anticlinal cell walls (Fig. 1). Straight to slightly curved cell walls are present on the abaxial side of A. breviscapa and A. variabilis (Fig. 1g, j), whereas the others have sinuate patterns of anticlinal cell walls (Fig. 1h, i, k, l). The cuticular striation is shown on both sides of the lamina in all morpho-types (Fig. 2). However, A. kerrii possesses numerous trichomes on the abaxial leaf surface which interfere with viewing the surface (Fig. 2h).
Table 3

Leaf epidermal characters of all morpho-types in summary

Name

Adaxial epidermis

Abaxial epidermis

Stomatal index (S.I.)a

Epidermal cell wall

Cuticle

Stomatal type

Non glandular trichome and length (µm)

Density of trichome

Stomatal index (S.I.)a

Epidermal cell wall

Cuticle

Stomatal type

Non glandular trichome and length (µm)

Density of trichome

A. breviscapa

8.92 ± 2.76

Str-cur

Striated

Ani-para

LS = 546–820

SS = 311–440

+

24.92 ± 3.35

Str-cur

Striated

Ani-para

LS = 569–1291

SS = 249–487

++

A. breviscapa

13.68 ± 4.45

Str-cur

Striated

Ani-para

LS = 563–981

SS = 296–444

+

25.33 ± 6.87

Str-cur

Striated

Para

LS = 1053–1499

SS = 217–462

++

A. kerrii

2.42 ± 1.45

Str-cur

Striated

Para

LS = 512–738

SS = 280–402

++

22.87 ± 3.63

Sinuate

Striated

Para

LS and SC

NT

+++

A. suddeeana

6.04 ± 2.23

Str-cur

Striated

Ani-para

LS = 515–945

SS = 128–410

+

26.84 ± 6.77

Sinuate

Striated

Para

LS = 583–1599

SS = 110–451

+++

A. suddeeana

7.19 ± 3.14

Str-cur

Striated

Ani-para

LS = 525–1037

SS = 149–313

+

25.70 ± 1.39

Sinuate

Striated

Para

LS = 667–1478

SS = 172–446

+++

A. variabilis

3.54 ± 1.05

Str-cur

Striated

Para

LS = 565–1100

SS = 155–478

+

33.21 ± 6.65

Str-cur

Striated

Para

LS = 796–1616

SS = 259–440

+++

A. variabilis

0.58 ± 1.32

Str-cur

Striated

Para

LS = 665–1295

SS = 145–420

+

25.46 ± 4.10

Str-cur

Striated

Para

LS = 948–1625

SS = 206–432

+++

Argyreia 1

4.37 ± 2.05

Sinuate

Striated

Ani-para

LS = 572–1042

SS = 142–391

+

22.22 ± 3.88

Sinuate

Striated

Para

LS = 617–1583

SS = 207–434

+++

Argyreia 2

5.21 ± 2.18

Str-cur

Striated

Ani-para

LS = 528–1073

SS = 197–428

+

27.68 ± 3.85

Sinuate

Striated

Para

LS = 708–1496

SS = 154–310

+++

Argyreia 2

10.71 ± 4.13

Str-cur

Striated

Ani-para

LS = 548–903

SS = 183–363

+

29.56 ± 3.08

Sinuate

Striated

Para

LS = 713–1673

SS = 173–305

+++

Argyreia 2

9.56 ± 1.32

Str-cur

Striated

Ani-para

LS = 551–1304

SS = 131–306

+

25.00 ± 2.77

Sinuate

Striated

Para

LS = 884–1994

SS = 144–424

+++

Argyreia 2

8.03 ± 2.47

Str-cur

Striated

Ani-para

LS = 544–824

SS = 173–390

+

24.42 ± 6.45

Sinuate

Striated

Para

LS = 685–1452

SS = 144–359

++

Argyreia 2

9.49 ± 4.75

Str-cur

Striated

Ani-para

LS = 523–945

SS = 160–318

+

25.00 ± 3.46

Sinuate

Striated

Para

LS = 661–1497

SS = 148–386

++

NT numerous trichome, Str-cur straight to slightly curved, Ani-para anisocytic and paracytic, Para paracytic, 10X trichome density, + 1‒5 trichomes, ++ 6‒10 trichomes, +++ more than 10 trichomes, LS large straight trichome, SS small straight trichome, SC small curly trichome

aMean ± SD

Fig. 1

The epidermal cell walls on adaxial (af) and abaxial leaf surfaces (gl) under light microscope (LM). a A. breviscapa, b A. kerrii, c A. suddeeana, d A. variabilis and f Argyreia 2, straight to slightly curved walls. e Argyreia 1, sinuate walls. g A. breviscapa and j A. variabilis, straight to slightly curved. h A. kerrii, i A. suddeeana, k Argyreia 1 and l Argyreia 2, sinuate (ep epidermal cell, st stomata, tr trichome). Scale bar 50 µm

Fig. 2

Cuticle ornamentation on adaxial (af) and abaxial leaf surfaces (gl) from SEM. a, g A. breviscapa, b, h A. kerrii, c, i A. suddeeana, d, j A. variabilis, e, k Argyreia 1 and f, l Argyreia 2 (gt glandular trichome, lst large straight trichome, sst small straight trichome, sct small curly trichome, st stomata, sco striate cuticular ornamentation). Scale bar 100 µm

Type of stomata and stomatal index

All of the morpho-types have amphistomatous leaves. The stomata on the adaxial leaf surface are anisocytic and paracytic in most of the morpho-types, excluding A. kerrii and A. variabilis, in which only the paracytic stomatal type was found. Conversely, a paracytic stomatal type presents on the abaxial leaf surface of every morpho-type, whereas A. breviscapa possesses both anisocytic and paracytic stomata (Table 3). On the adaxial epidermis the highest stomatal index was observed in A. breviscapa and the lowest in A. variabilis. On the other hand, the highest stomatal index on the abaxial epidermis was found in A. variabilis and the lowest in Argyreia 1 (Table 3).

Type, density, size and length of trichomes

Two types of trichomes are present in all morpho-types (Table 3): peltate glandular and simple non-glandular trichomes. Three types of non-glandular trichomes were recognized based on their length and direction: i.e. large straight; small straight; and small curly trichomes were found (Table 3). On their adaxial leaf surfaces, all of the morpho-types possess large and small, straight trichomes (Fig. 3a–f). Similarly on the abaxial leaf surfaces, most morpho-types have large and small straight trichomes excluding A. kerrii, which has large straight alternating with small curly trichomes (Fig. 3g–l). The longest trichomes on the adaxial epidermis occur in A. variabilis, while the shortest ones are in A. suddeeana (Table 3). Meanwhile, the longest trichomes on abaxial epidermis are in A. breviscapa and the shortest in A. suddeeana (Table 3).
Fig. 3

Trichomes on adaxial (af) and abaxial leaf surfaces (gl) under light microscopy (LM). a, g A. breviscapa, b, h A. kerrii, c, i A. suddeeana, d, j A. variabilis, e, k Argyreia 1 and f, l Argyreia 2 (lst large straight trichome, sst small straight trichome, sct small curly trichome, st stomata). Scale bar 200 µm

Transverse section of leaf blade and petiole

Leaf blades of all six morpho-types have one layer of epidermis with thin cuticle (Fig. 4). Adaxial epidermal cells are irregular to round in shape excluding A. variabilis, which has long and narrow shaped cells (Fig. 4d). Argyreia breviscapa, A. kerrii, and A. suddeeana have dark-staining deposits in some of the cells on the adaxial surface (Fig. 5a–c). Palisade and spongy cells are different in shape. Palisade parenchyma is composed of 1‒2 cell layers. Most morpho-types have rounded leaf margins (Fig. 4g–i, k, l), except A. variabilis, which has acute margins (Fig. 4j) (Table 4).
Fig. 4

Transverse sections of leaf blade (af) and leaf margin (gl). a, g A. breviscapa, b, h A. kerrii, c, i A. suddeeana, d, j A. variabilis, e, k Argyreia 1 and f, l Argyreia 2 (ds dark-staining deposit, ep epidermal cell, pc palisade cell, sc spongy cell, tr trichome, vt vascular tissue). Scale bar 100 µm

Fig. 5

Transverse sections of midrib (af) and petiole (gl). a, g A. breviscapa, b, h A. kerrii, c, i A. suddeeana, d, j A. variabilis, e, k Argyreia 1 and f, l Argyreia 2 (a adaxial curvature, ch chlorenchyma cell, cvo convex outline, sco slightly concave outline, se secretory cavity, vt vascular tissue). Scale bar 500 µm

Table 4

Leaf and petiole transverse section characters in summary

Name

Petiole outline

Cross-sectional petiole size (mm)

Midrib outline and adaxial curvature

Cross-sectional midrib size (mm)

Leaf blade width (µm)

Leaf margins

Width

Height

Width

Height

A. breviscapa

Convex

2.02 ± 0.05

2.10 ± 0.04

Convex with acute adaxial curvature

1.17 ± 0.24

1.03 ± 0.08

269.40 ± 35.64

Round

A. breviscapa

Convex

1.98 ± 0.02

2.28 ± 0.11

Convex with acute adaxial curvature

1.19 ± 0.08

1.14 ± 0.07

211.77 ± 7.84

Round

A. kerrii

Concave

1.73 ± 0.03

1.76 ± 0.23

Convex with round adaxial curvature

1.01 ± 0.06

0.95 ± 0.05

198.70 ± 45.96

Round

A. suddeeana

Concave

2.01 ± 0.17

2.06 ± 0.12

Convex with round adaxial curvature

1.40 ± 0.29

1.21 ± 0.15

183.03 ± 3.46

Round

A. suddeeana

Concave

1.51 ± 0.15

1.65 ± 0.12

Convex with round adaxial curvature

0.96 ± 0.31

0.92 ± 0.08

291.23 ± 28.90

Round

A. variabilis

Convex

2.24 ± 0.09

2.77 ± 0.39

Convex with round adaxial curvature

1.33 ± 0.12

1.34 ± 0.12

177.60 ± 29.23

Acute

A. variabilis

Convex

1.98 ± 0.58

2.34 ± 0.59

Convex with round adaxial curvature

1.52 ± 0.20

1.26 ± 0.15

244.87 ± 44.14

Acute

Argyreia 1

Concave

1.47 ± 0.18

1.24 ± 0.15

Convex with round adaxial curvature

0.85 ± 0.26

0.71 ± 0.10

162.53 ± 11.59

Round

Argyreia 2

Convex

1.99 ± 0.19

2.20 ± 0.02

Convex with round adaxial curvature

1.34 ± 0.17

1.26 ± 0.13

191.53 ± 9.76

Round

Argyreia 2

Convex

1.44 ± 0.09

1.82 ± 0.02

Convex with round adaxial curvature

0.91 ± 0.09

0.94 ± 0.06

171.83 ± 22.91

Round

Argyreia 2

Convex

1.52 ± 0.12

1.84 ± 0.04

Convex with round adaxial curvature

0.98 ± 0.12

1.05 ± 0.07

174.57 ± 33.96

Round

Argyreia 2

Convex

1.43 ± 0.09

1.83 ± 0.07

Convex with round adaxial curvature

0.91 ± 0.10

1.05 ± 0.01

156.73 ± 14.62

Round

Argyreia 2

Convex

1.73 ± 0.03

1.73 ± 0.23

Convex with round adaxial curvature

0.95 ± 0.09

0.92 ± 0.04

220.97 ± 16.15

Round

Outlines of the midrib are convex on the adaxial surface with a single acute to rounded adaxial curvature, while abaxial side are rounded or flattened. Almost all have rounded adaxial curvature (Fig. 5b–f), except A. breviscapa (Fig. 5a). Vascular tissue in the midrib is bicollateral type (Fig. 5a–f). Secretory cavities occur in all morpho-types, especially in A. kerrii (Fig. 5b). The largest cross-sectional midrib size is in A. variabilis and the smallest in Argyreia 1 (Table 4). Druse crystals are commonly found in the petioles, midribs, and leaf blades of all.

Petiole transverse section outlines are convex in A. breviscapa, A. variabilis and Argyreia 2 (Fig. 5g, j, l), while A. kerrii, A. suddeeana and Argyreia 1 show slightly concave outlines on the adaxial surface (Fig. 5h, i, k). Chlorenchyma comprises three to five cell layers in the cortex. Secretory cavities with thin walls are present in the ground parenchyma of all the morpho-types, particularly in A. kerrii (Fig. 5h). The vascular tissue of the petioles in all morpho-types consists of three bicollateral bundles. The largest cross-sectional petiole size is shown in A. variabilis and the smallest in Argyreia 1 (Table 4).

Cluster analysis

The phenogram of Argyreia morpho-types (Fig. 6) using 24 anatomical traits (Table 2) was constructed by UPGMA algorithm, for which the cophenetic correlation coefficient (or R value) was equal to 0.87. The high R value (>0.8) indicated the suitability of morpho-types clustering. From the phenogram, four major clusters (A, B, C, and D) were distinctly recognized by similarity coefficient from at least 0.60 and up to 0.70 (Fig. 6). The first cluster A comprises two accessions of A. breviscapa; it had a high similarity coefficient around 0.70. Cluster B contains only one morpho-type, A. kerrii, whereas the adjacent cluster C was separated from A. kerrii at similarity coefficient around 0.60. The cluster C contains two samples of A. variabilis that had a similarity coefficient about 0.71. The last cluster D was separated from the other clusters by a similarity coefficient about 0.72, and formed two subgroups. The subgroup E comprises two accessions of A. suddeeana that had a high similarity coefficient around 0.88. The second subgroup, F, is composed of two Argyreia morpho-types which are a single accession of Argyreia 1, and a group of five samples of Argyreia 2 that mutually diverged from each other with the similarity coefficient of 0.74. Five accessions of Argyreia 2 were obviously separated from Argyreia 1 at around 0.81 of similarity coefficient. Moreover, Argyreia 2 was subdivided into one subgroup (accession numbers 9 and 11) with high similarity coefficient of 0.88, and a second subgroup (accession numbers 10, 12 and 13) with the same value of similarity (0.88).
Fig. 6

Phenogram for six Argyreia morpho-types from cluster analysis based on UPGMA method using 24 anatomical traits; the vertical dashed line indicates similarity coefficient; parenthetical numbers (1)–(13) indicate accession number of plant materials cited in Table 1

Principal component analysis

The PCA resulting from examination of 24 anatomical characters (Table 5) from 13 Argyreia accessions representing six morpho-types showed the scatter plots of four clusters (Fig. 7). The two accessions of A. breviscapa in cluster A, and also both samples of A. variabilis in cluster C were quite loosely grouped, assuming that they were affected by the first component, while a single accession of A. kerrii was isolated from them. The large cluster, D, was formed into two subgroups, E and F. The morpho-types of subgroup E were closely grouped together, whereas those in subgroup F were widely separated by the first component.
Table 5

Factor loading and cumulative eigenvalue percentage received from 24 leaf anatomical characters

Anatomical characters

Component

1

2

1. Epidermal cell wall on adaxial leaf surface

0.024

−0.086

2. Epidermal cell wall on abaxial leaf surface

0.071

0.397

3. Types of non-glandular trichome on abaxial leaf surface

0.051

0.059

4. Shape of petiole

0.076

0.131

5. Midrib outline and adaxial curvature

−0.217

0.153

6. Leaf margin shape

0.146

0.245

7. Ratio of adaxial leaf epidermal cell size

0.051

0.059

8. Stomatal index (SI) on adaxial leaf surface

−0.193

0.067

9. Ratio of stomatal size on adaxial leaf surface

−0.124

0.281

10. Ratio of glandular trichome size on adaxial leaf surface

−0.202

0.118

11. Ratio of non-glandular trichome size on adaxial leaf surface

0.000

−0.163

12. Ratio of abaxial leaf epidermal cell size

0.093

0.172

13. Stomatal index (SI) on abaxial leaf surface

0.222

0.159

14. Ratio of stomatal size on abaxial leaf surface

0.043

0.113

15. Ratio of glandular trichome size on abaxial leaf surface

−0.197

−0.304

16. Ratio of non-glandular trichome size on abaxial leaf surface

−0.448

−0.229

17. Ratio of epidermal cell size in petiole

0.122

0.390

18. Ratio of petiole transverse section

−0.430

0.026

19. Ratio of palisade mesophyll cell size in leaf transverse section

0.076

0.063

20. Ratio of spongy mesophyll cell size in leaf transverse section

−0.114

0.284

21. Ratio of adaxial epidermal cell size in leaf transverse section

0.177

0.103

22. Ratio of abaxial epidermal cell size in leaf transverse section

0.108

−0.245

23. Blade thickness

−0.504

0.243

24. Ratio of midrib thickness

0.083

−0.156

Eigenvalue

1.3776

1.0784

Cumulative % of eigenvalue

28

49.9

Fig. 7

The scattered plot of first and second components obtained from principal component analysis (PCA) based on 24 anatomical traits. Group A, B, C, D and subgroups E and F corresponding to the phenogram in Fig. 6

The first two components accounted respectively for 28 and 21.9% of the total variance (Table 5). In the first component, the one character with high positive factor loading was stomatal index on the abaxial leaf surface (13), while high negative factor loading were the ratio of non-glandular trichome size on abaxial leaf surface (16); ratio of petiole transverse section (18); and blade thickness (23). The second component was weighted heavily positive for epidermal cell walls on abaxial leaf surface (2), and ratio of epidermal cell size in petiole (17), whereas it was negative for ratio of glandular trichome size on abaxial leaf surface (15), and ratio of non-glandular trichome size on abaxial leaf surface (16).

Discussion and conclusions

The anatomical characters that are informative for identifying these six morpho-types are the epidermal cell walls and trichome types on the leaf surfaces. Moreover, the characters from leaf transverse section were also useful to distinguish each morpho-type such as the shape of adaxial epidermal cells of the leaf blades, the shape of leaf margins and the outline of petioles.

Epidermal cell wall

Two types of epidermal cell walls are found on both surfaces: straight to slightly curved, and sinuate. This finding is in agreement with the investigations by Metcalfe and Chalk (1950) and Tayade and Patil (2003, 2012c). Argyreia 1 is the only one that possesses sinuate epidermal cell walls on the adaxial surface, whereas most of them have this type of epidermal cell wall on the abaxial side, except A. breviscapa and A. variabilis. Argyreia breviscapa is quite similar to Argyreia 1 in terms of morphological characters, especially when compared as pressed and dried herbarium specimen. This study shows that observation of the epidermal cell walls can separate A. breviscapa from Argyreia 1, and cluster analysis (CA) further revealed that these two morpho-types are placed in different clusters with similarity coefficient of 0.53 (Fig. 6). This suggests that the two morpho-types are not the same taxon. Further investigations, using different techniques such as molecular genetics, are required for more accurate characterization.

Type of stomata and stomatal index

Plants in the family Convolvulaceae generally have amphistomatic leaves with paracytic type of stomata, rarely anisocytic (Metcalfe and Chalk 1950; Tayade and Patil 2003, 2012b). The results from this study agreed with the previous researches; nevertheless, anisocytic stomata were present in four morpho-types. The stomatal frequency on both leaf surfaces varies in each morpho-type; this is considered systematically significant and may be connected with the ecology of the plants (Stace 1965). Commonly, the stomatal index (SI) might vary depending on light intensity, humidity, and level of air pollution (Nikolić and Mitić 1991). However, both the stomatal frequency and stomatal index were treated as useful characters for diagnostic purposes (Metcalfe and Chalk 1979).

Trichomes and cuticular pattern on leaf surfaces

Trichomes are known to play essential roles in protecting plants from chilling, drought, UV radiation, disease infection, and particularly against insect herbivory (Liakoura et al. 1997; Pfeiffer et al. 2003). Furthermore, trichome density may vary due to genetic as well as environmental factors, including water and mineral nutrients or the accumulation of water which alters leaf size (Johnson 1975; Wilkens et al. 1996; Roy et al. 1999).

Both glandular and non-glandular trichomes are present in Argyreia. Trichomes are normally present on both leaf surfaces in the six morpho-types studied. Finding glandular peltate trichomes in all morpho-types corresponded to reports in the previous studies by Tayade and Patil (2012a, c). Non-glandular trichomes, both large and small straight unicellular types, are found in all the morpho-types, but the large straight and small curly trichomes occur only on the abaxial surface of A. kerrii. The CA result also confirmed that A. kerrii is separated from cluster C with a 0.602 similarity coefficient (Fig. 6).

Cuticular striations occur in all six morpho-types studied. The diversity of patterning on the cuticular layers can be conveniently employed in taxonomic delineations in this family, as suggested by Tayade and Patil (2003). Our recent paper showed that the cutin layer can distinguish two morphologically similar species, A. albiflora and A. wallichii (Staples et al. 2015).

Transverse sections of leaf blade and petiole

Characters obtained from leaf transverse sections in this research are in agreement with previous studies (Metcalfe and Chalk 1950; Tayade and Patil 2012b, c) that demonstrated all Argyreia leaves are dorsiventral; the leaf blades of every morpho-type have one layer of epidermis; and the mesophyll is composed of palisade and spongy cells. Additionally, there are some dark-staining deposits, which could be flavonoids or alkaloids, in some of the epidermal cells on the adaxial surface. This occurrence corresponded to the study of loline alkaloids in Argyreia mollis (Burm.f.) Choisy, which also can be found in roots and aerial vegetative parts of plants (Tofern et al. 1999; Mann et al. 1999; Tayade and Patil 2012b).

The epidermal cell shapes of leaf blade in transverse section of A. variabilis show long and narrow shapes and its leaf margins are acute, which is different from the other morpho-types. This coincides with phenetic result that show two accessions of A. variabilis separated from cluster B (Fig. 6) in cluster analysis by similarity coefficient of 0.602 and forming a distinct cluster C. The epidermal cell shape character and results from phenetic analyses can be used to point out that Argyreia 2 is different from A. variabilis.

The vascular tissue of the petiole in the family Convolvulaceae commonly exhibits bicollateral bundles (Metcalfe and Chalk 1950; Tayade and Patil 2012a, c). The results from this research correspond to the prior studies.

Shape of the Argyreia petiole in transverse section is convex (Fig. 5g, j, l) or slightly concave (Fig. 5h, i, k) on the adaxial side, as also seen in the study of genus Merremia Dennst. ex. Endl. (Pisuttimarn et al. 2013). In our results, half the taxa have convex petiole shape (A. breviscapa, A. variabilis, and Argyreia 2), whereas in A. kerrii, A. suddeeana and Argyreia 1, petioles have a concave shape (about 1/6 of the length of the petiole). The result from CA indicated that A. suddeeana, Argyreia 1, and Argyreia 2 were grouped together in the same cluster (D), however, A. suddeeana was separated from this group forming a subgroup E, at similarity coefficient about 0.718 (Fig. 6). Therefore, the outline of petiole can be used to separate A. suddeeana from Argyreia 2.

Druse crystals (calcium oxalate) are commonly found in petiole, midrib, and leaf blade of all six morpho-types, which agrees with the previous investigations by Metcalfe and Chalk (1950), Sayeedud-Din (1953) and Tayade and Patil (2012a, c). The druse crystal has many functions in plants including calcium regulation, ion balance, tissue support, plant protection, detoxification and light assembly and reflection (Franceschi and Horner 1980; Nakata 2003). Recent research about druse crystals in a C4 plant, Amaranthus hybridus L., revealed that the plant used calcium oxalate crystals as a non-atmospheric carbon source in photosynthesis assimilation during the day, especially in drought condition (Tooulakou et al. 2016). In the daytime, druse crystals were degraded and provided subsidiary carbon used in photosynthesis under ambient conditions that caused stomatal closure (for preventing water loss). Moreover, these crystals were recovered during the night as a biochemical carbon reservoir.

Numerous secretory cavities in the ground tissue of the petiole and midrib are also observed in A. kerrii, in agreement with previous researches, which reported that plants in this family possess secretory cavities in the ground tissue of leaf, petiole, and stem (Metcalfe and Chalk 1950; Sayeedud-Din 1953; Tayade and Patil 2012a, c).

Although the results from this study were consistent with earlier anatomical studies they incrementally increase the fundamental knowledge base about the genus Argyreia and point the way for further study. Rather few plant samples in genus Argyreia were examined previously; in this study, we investigated several more Argyreia taxa that have not been studied before. Furthermore, our data demonstrate that anatomical traits can provide informative characters that have a useful role for plant identification. Argyreia has proven to be an extraordinarily complex genus and species delimitation is difficult, especially in the complexes of vegetatively similar species where floral characters have been the only reliable method to discriminate taxa. Accordingly, evidence from methods and techniques outside the usual morphological ones must be explored to determine whether they afford taxonomically informative characters. Since the genus Argyreia is one of the larger genera in the family Convolvulaceae comprising around 135 species (Staples and Traiperm 2017) the results from our study expand the baseline for understanding morphological and anatomical diversity within and between species.

Declarations

Authors’ contributions

PT created the study topic, collected the plants, planned the study, guided all lab work, drafted, revised and developed the manuscript, prepared the manuscript for submission. JC analyzed the anatomical data and drafted some parts of the manuscript. PN analyzed the CA and PCA data and drafted some parts of the manuscript. GWS planned the study, guided taxonomic identifications, provided important taxonomic literatures, drafted, revised, developed the manuscript and polished the English. SCS guided lab work. All authors read and approved the final manuscript.

Acknowledgements

We would like to thank the Department of Plant Science, Faculty of Science, Mahidol University for laboratory facilities. Thanks also to Wirata Rujichaipimon for help in preparing the colour photos. Traiperm wishes to acknowledge the Thailand Research Fund (TRF), RSA5880022 and the Faculty of Science, Mahidol University for financial support. GS gratefully acknowledges funding support from Faculty of Graduate Studies, Mahidol University, which facilitated our collaboration.

Competing interests

The authors declare that they have no competing interests.

Funding

The Thailand Research Fund (TRF), RSA5880022, the Faculty of Science and Faculty of Graduate Studies, Mahidol University.

Publisher’s Note

Springer Nature remains neutral with regard to jurisdictional claims in published maps and institutional affiliations.

Open AccessThis article is distributed under the terms of the Creative Commons Attribution 4.0 International License (http://creativecommons.org/licenses/by/4.0/), which permits unrestricted use, distribution, and reproduction in any medium, provided you give appropriate credit to the original author(s) and the source, provide a link to the Creative Commons license, and indicate if changes were made.

Authors’ Affiliations

(1)
Department of Plant Science, Faculty of Science, Mahidol University
(2)
Department of Pharmaceutical Botany, Faculty of Pharmacy, Mahidol University
(3)
HRA, Herbarium, Royal Botanic Gardens

References

  1. Aghababaeyan E, Pakravan M, Ghahremaninejad F (2014) Anatomical study and pollen micromorphology of Onopordum L. in Iran. Notulae Scientia Biologicae 6(1):66–76View ArticleGoogle Scholar
  2. Arthan W, Traiperm P, Gale SW, Norsaengsri M, Kethirun L (2016) Re-evaluation of the taxonomic status of Hackelochloa (Poaceae) based on anatomical and phenetic analyses. Bot J Linn Soc 181(2):224–245View ArticleGoogle Scholar
  3. Breitwieser I, Ward JM (1993) Systematics of New Zealand Inuleae (Compositae-Asteraceae)-3 numerical phenetic analysis of leaf anatomy and flavonoids. N Z J Bot 31(1):43–58View ArticleGoogle Scholar
  4. De Faria AP, Wendt T, Brown GK (2010) A revision of Aechmea subgenus Macrochordion (Bromeliaceae) based on phenetic analyses of morphological variation. Bot J Linn Soc 162(1):1–27View ArticleGoogle Scholar
  5. Franceschi VR, Horner HT (1980) Calcium oxalate crystals in plants. Bot Rev 46(4):361–427View ArticleGoogle Scholar
  6. Jayarathna SP, Senanayake SP, Rajapakse S, Jayasekera LR (2016) Phenetic variation and preliminary phytochemical screening of Piper species in Sri Lanka. J Agric Sci 11(3):155–163Google Scholar
  7. Johansen DA (1940) Plant microtechnique, 1st edn. McGraw-Hill Book, New YorkGoogle Scholar
  8. Johnson HB (1975) Plant pubescence: an ecological perspective. Bot Rev 41:233–258View ArticleGoogle Scholar
  9. Liakoura V, Stefanou M, Manetas Y, Cholevas C, Karabourniotis G (1997) Trichome density and its UV-B protective potential are affected by shading and leaf position on the canopy. Environ Exp Bot 38(3):223–229View ArticleGoogle Scholar
  10. Mann P, Tofern B, Kaloga M, Eich E (1999) Flavonoid sulfates from the Convolvulaceae. Phytochemistry 50(2):267–271View ArticleGoogle Scholar
  11. Metcalfe CR, Chalk L (1950) Convolvulaceae. In: Metcalfe CR, Chalk L (eds) Anatomy of the dicotyledons, vol 2. Clarendon Press, Oxford, pp 954–964Google Scholar
  12. Metcalfe CR, Chalk L (1979) Anatomy of the dicotyledons, vol 1, 2nd edn. Clarendon Press, OxfordGoogle Scholar
  13. Minitab (2010) Minitab 16 statistical software. Minitab Inc, State CollegeGoogle Scholar
  14. Moraes TM, Rabelo GR, Alexandrino CR, Silva Neto SJ, Da Cunha M (2011) Comparative leaf anatomy and micromorphology of Psychotria species (Rubiaceae) from the Atlantic Rainforest. Acta Bot Bras 25(1):178–190View ArticleGoogle Scholar
  15. Nakata PA (2003) Advances in our understanding of calcium oxalate crystal formation and function in plants. Plant Sci 164(6):901–909View ArticleGoogle Scholar
  16. Nikolić T, Mitić B (1991) Phenetic relationships within populations of Iris illyrica, I. pallida and I. pseudopallida (Iridaceae) with regard to morphological characteristics of epidermis. Acta Bot Croat 50(1):99–106Google Scholar
  17. Pant DD, Bhatnagar S (1975) Morphological studies in Argyreia Lour. (Convolvulaceae). Bot J Linn Soc 70(1):45–69View ArticleGoogle Scholar
  18. Pfeiffer TW, Peyyala R, Ren Q, Ghabrial SA (2003) Increased soybean pubescence density: yield and soybean mosaic virus resistance effects. Crop Sci 43:2071–2076View ArticleGoogle Scholar
  19. Pisuttimarn P, Traiperm P, Pornpongrungrueng P (2013) Comparative anatomy of Merremia section Xanthips (Convolvulaceae) in Thailand. In: Proceedings in the national graduate research conference 29th (NGRC29) (in Thai), pp 93–101Google Scholar
  20. Rohlf FJ (2000) NTSYS-pc: numerical taxonomy and multivariate analysis system, version 2.1. Exeter Software, New YorkGoogle Scholar
  21. Roy BA, Stanton ML, Eppley SM (1999) Effects of environmental stress on leaf hair density and consequences for selection. J Evol Biol 12(6):1089–1103View ArticleGoogle Scholar
  22. Salisbury EJ (1927) On the causes and ecological significance of stomatal frequency, with special reference to the woodland flora. Philos Trans R Soc Lond 216:1–65View ArticleGoogle Scholar
  23. Sayeedud-Din M (1953) Observations on the anatomy of some of the Convolvulaceae. Bot J Linn Soc 37:106–109Google Scholar
  24. Stace CA (1965) Cuticular studies as an aid in plant taxonomy. Bull Brit Mus (Nat Hist) Bot 4:1–78Google Scholar
  25. Staples GW, Traiperm P (2008) New species, new combinations, and new records in Convolvulaceae for the Flora of Thailand. Thai Forest Bull Bot 36:86–108Google Scholar
  26. Staples GW, Traiperm P (2017) A nomenclatural review of Argyreia (Convolvulaceae). Taxon 66:445–477View ArticleGoogle Scholar
  27. Staples GW, Traiperm P, Chow J (2015) Another new Thai Argyreia species (Convolvulaceae). Phytotaxa 204(3):223–229View ArticleGoogle Scholar
  28. Tayade SK, Patil DA (2003) Foliar epidermal features and their taxonomic significance in the genus Argyreia Lour. (Convolvulaceae). J Swam Bot Club 20:15–18Google Scholar
  29. Tayade SK, Patil DA (2012a) Anatomical studies of stem in some species of Convolvulaceae. Int J Sci Pharm Educ Res 1(2):42–46Google Scholar
  30. Tayade SK, Patil DA (2012b) Leaf anatomical studies in some species of Convolvulaceae. Life Sci Leafl 3:64–74Google Scholar
  31. Tayade SK, Patil DA (2012c) The family Convolvulaceae: anatomical conspectus. World J Sci Technol 2(6):42–50Google Scholar
  32. Thadeo M, Azevedo AA, Meira RM (2014) Foliar anatomy of neotropical Salicaceae: potentially useful characters for taxonomy. Plant Syst Evol 300(9):2073–2089View ArticleGoogle Scholar
  33. Tofern B, Kaloga M, Witte L, Hartmann T, Eich E (1999) Occurrence of loline alkaloids in Argyreia mollis (Convolvulaceae). Phytochemistry 51(8):1177–1180View ArticleGoogle Scholar
  34. Tooulakou G, Giannopoulos A, Nikolopoulos D, Bresta P, Dotsika E, Orkoula MG, Kontoyiannis CG, Fasseas C, Liakopoulos G, Klapa MI, Karabourniotis G (2016) Alarm photosynthesis: calcium oxalate crystals as an internal CO2 source in plants. Plant Physiol 171(4):2577–2585PubMedGoogle Scholar
  35. Traiperm P, Staples GW (2014) A new endemic Thai species of Argyreia (Convolvulaceae). Phytotaxa 164(4):281–285View ArticleGoogle Scholar
  36. Wilkens RT, Shea GO, Halbreich S, Stamp NE (1996) Resource availability and the trichome defense of tomato plants. Oecologia 106(2):181–191View ArticlePubMedGoogle Scholar

Copyright

© The Author(s) 2017
