Seed dispersal in Neuwiedia singapureana: novel evidence for avian endozoochory in the earliest diverging clade in Orchidaceae
Botanical Studies volume 62, Article number: 3 (2021)
Seed dispersal allows plants to colonize new habitats that has an significant influence on plant distribution and population dynamics. Orchids produce numerous tiny seeds without endosperm, which are considered to be mainly wind-dispersed. Here, we report avian seed dispersal for an early diverging orchid species, Neuwiedia singapureana, which produces fleshy fruits with hard seed coats in the understory of tropical forests.
Neuwiedia singapureana produced fleshy fruits that turned red in autumn, and birds were confirmed to be the primary seed dispersers. As compared to its sister species, N. veratrifolia with dehiscent capsular fruits, embryos of N. singapureana were larger and enclosed by thickened and lignified seed coats. After passing through the digestive tracts of birds, the seeds still stayed alive, and the walls of seed coat contained several cracks. The germination percentage increased significantly for digested seeds as compared with seeds from intact fruits.
The thickened and lignified seed coat may protect seeds as they passed through the digestive tracts of birds. Taken together with a recent report of insect-mediated seed dispersal system in the subfamily Apostasioideae, the animal-mediated seed dispersal may be an adaptive mechanism promoting the success of colonization in dark understory habitats.
Seed dispersal has an important influence on plant distribution, abundance and population dynamics because it determines the future locations where seeds and later seedlings will survive or expire (Eriksson 2000). In plants, dispersal methods could greatly differ, including by animals (e.g., birds, bats, primates, rodents and fishes), water, wind and gravity (Howe and Smallwood 1982). Various fruit features have been interpreted as coadapted traits of plants that influence the strategy of seed dispersal, such as fruit density, dehiscence, color, palatability, weight and nutrient content (Smith 2001). Orchidaceae is one of the largest angiosperm families with an estimated 800 genera and more than 24,000 species mainly inhabiting subtropical and tropical regions (World Checklist of Monocotyledons, 2006). Upon a successful pollination event in orchids, numerous and tiny seeds are produced in a fruit (Arditti 1992). Furthermore, the tiny orchid seed contains an undifferentiated embryo without endosperm covered by a thin layer of seed coat (Dressler 1993). These characters are considered to be an adaptation for wind dispersal (Arditti and Ghani 2000).
Most orchids possess dehiscent, capsular fruits, while indehiscent, fleshy fruits have been observed only in a few genera across different subfamilies, such as Neuwiedia (subfamily Apostasioideae), Selenipedium (subfamily Cypripedioideae), Cyrtosia (subfamily Vanilloideae), and Yoania (subfamily Epidendroideae) (Dressler 1989; Clements and Molvray 1999; Kocyan and Endress 2001; Suetsugu 2018a,b). So far no fleshy fruit is reported in any genus of subfamily Orchidoideae.
The subfamily Apostasioideae (containing two genera—Apostasia and Neuwiedia) has been considered as the earliest-diverging lineage of Orchidaceae, which possesses several unique characters, including actinomorphic flower, three stamens and powdery pollen grains (Kocyan and Endress 2001). In addition, the presence of indehiscent fruits and the thickened seed coat in some Apostasia and Neuwiedia species (Nishimura and Tamura 1993; Clements 1999) are suggested to be plesiomorphic characters. Recently, Suetsugu (2020) reported that Apostasia nipponica possesses green inconspicuous and indehiscent fruits and depends on cricket/camel cricket species for seed dispersal. In our field investigations, Neuwiedia singapureana produces several fleshy fruits on a spike that turn red once they are ripe. This character implies the seed dispersal by birds.
In this study, fruits of N. singapureana were monitored by remote cameras to record the consumers. The histological feature of N. singapureana mature seeds was investigated. In order to know if the trait of fleshy/capsular fruits is correlated with the seed character, we compared the seed morphology and embryo size of N. singapureana and its sister species, N. veratrifolia with capsular fruits. To investigate whether the seeds could survive after consumption by birds, we fed the fruits of N. singapureana and N. veratrifolia to birds and collected seeds from faeces for viability testing by 2,3,5-triphenyl tetrazolium chloride (TTC) staining. The morphology of seed coat between intact and defecated seeds was compared by scanning electron microscope.
Study site and investigations
Neuwiedia singapureana is a terrestrial orchid species found in the broad-leaved evergreen forest. Field studies were conducted between 2015 and 2016 in the Diaoluo Mountain region in Hainan, China. Voucher specimens of N. singapureana were deposited in the herbarium of the National Museum of Nature and Science, Taiwan (accession nos.: Yung-I Lee 201601). Consumers of N. singapureana fruits were monitored in the field by remote cameras that had built-in infrared motion sensors (Acorn Ltl 6210MC Wildlife Camera with 940 nm Covert Infrared & 1080P Video Recording, Zhuhai Ltl Acorn Electronics, Guangdong, China). Each camera was set up 1 m away from 10 N. singapureana plants to determine the animals feeding on the fruits. Observations were from 0820 and 1800 h during August 25 to 29 in 2015 and from 0900 to1600 h during August 20 to 23 in 2016.
Seeds were fixed in a solution of 2.5% glutaraldehyde in 0.1 M phosphate buffer (pH 6.8) for 24 h at room temperature, then samples were dehydrated with an ethanol series and embedded in Technovit 7100 (Kulzer & Co., Germany) as described (Yeung and Chan 2015). Sections of 3-µm thick were cut with glass knives by using a Reichert-Jung 2040 Autocut rotary microtome, then stained with 0.05% (w/v) toluidine blue O (TBO) in benzoate buffer and examined and captured digitally by using a CCD camera attached to a light microscope (Axio Imager A1, Carl Zeiss AG).
Comparison of seed morphology
Seed morphology was compared for N. singapureana with fleshy fruits and a closely related species, N. veratrifolia, with dehiscent, capsular fruits. Voucher specimens of N. veratrifolia were deposited in the herbarium of the National Museum of Nature and Science, Taiwan (accession nos.: Yung-I Lee 201232). The mature seeds of both Neuwiedia species were collected and dried in a desiccator and the relative humidity was maintained at 30%. The length and width of embryos were measured and recorded in 100 seeds for each species by using a light microscope (Axio Imager A1, Carl Zeiss AG). The embryo volume was calculated according to Arditti and Ghani (2000): [3π × (half length of embryo) × (half width of embryo)2/4].
Mature seeds of N. singapureana and N. veratrifolia before and after defecation by birds were collected and treated with 0.5% NaOCl solution (w/v) + 0.1% Tween-20 (v/v) for 1 h, then incubated with 1% 2,3,5-triphenyltetrazolium chloride solution at 27 °C for 5 d as described (Lee et al. 2005). Under a dissecting microscope, the embryos remaining yellow were considered unstained (dead), and those turning orange to red were considered stained (viable). The staining tests were replicated 3 times with 100 seeds in each replicate.
Scanning electron microscopy
For observing the damaged seed coat after consumption by birds, seeds were fixed in 1% (v/v) glutaraldehyde in 0.1 M sodium phosphate buffer, pH 6.8, for 24 h at room temperature. After dehydration in an alcohol–acetone series, samples were critical-point dried, sputter-coated with platinum and observed under a scanning electron microscope (S-4200, Hitachi, Tokyo) with an accelerating voltage of 15 kV.
Asymbiotic seed germination
To investigate the capacity of seed germination after consumption by birds, we collected 30 fruits that had been consumed by birds and performed asymbiotic seed germination experiments. The seeds defecated by birds were washed and collected for sterilization in 0.5% sodium hypochlorite solution with 0.1% Tween 20 (Sigma-Aldrich) for 15 min. For the control, seeds were sterilized only in sodium hypochlorite solution. After three rinses with sterile distilled water, seeds were placed onto 20-ml modified Murashige and Skoog (MS) medium (Murashige and Skoog 1962) in a 9-cm diameter Petri dish. The modified MS medium contained 1/4 strength macroelements with full-strength microelements (2 mg glycine, 0.5 mg niacin, 0.5 mg pyridoxine HCl, 0.1 mg thiamine, 100 mg myo-inositol, 20 g sucrose and 6 g agar/L). The pH was adjusted to 5.7 before autoclaving at 102 kPa and 121 °C for 20 min. The cultures were maintained in the growth room under darkness at 26 ± 2 °C. Experiments were performed in a randomized design and repeated three times. Twelve plates were used for each treatment, with a minimum of 100 seeds per plate. Each plate was examined and the germination percentage was scored monthly by using a stereomicroscope (Carl Zeiss AG, Germany). Germination was defined as emergence of the embryo from the testa.
The seed viability test and germination experiments were established in a completely randomized design and repeated three times. The data were statistically analyzed by one-way ANOVA followed by Fisher’s protected least significant difference test.
Flora and fruit morphology and seed structure
Each plant produced a single inflorescence bearing multiple creamy-white flowers (Fig. 1a). The flowering period for this species in the Diaoluo Mountain area occurs from June to July, and the ratio of fruit set was relatively high (Fig. 1b). Fruits turned red and became mature in October (Fig. 1c). In the cross section of a mature fruit, three locules were filled with numerous black seeds (mean number of seeds per fruit, 2024.2 ± 390.1) attached to the axile placenta (Fig. 1d). The embryo was about nine cells long and six cells wide (Fig. 1d). In the seed coat, the inner periclinal and anticlinal walls were very thick as compared with the outer periclinal wall (Fig. 1e). Moreover, the thickened wall of the seed coat stained greenish blue with TBO, indicating the presence of phenolic compounds in the walls.
Fruits consumed by birds
We monitored the fruits of N. singapureana for a total of 3,768 h in the field by using motion sensor-equipped cameras: the fruits were commonly eaten by two species of birds (Alophoixus pallidus and Lophura nythemera) (Table 1; Fig. 1f; Additional file 2: Video S1).
Neuwiedia singapureana had oval shape seeds within the fleshy fruit, while N. veratrifolia had linear seeds within the dehiscent, capsular fruit (Table 2; Fig. 2). Besides, embryo lengths, widths and volumes significantly differed between N. singapureana and N. veratrifolia (Table 2).
Mature seeds and seeds defecated from birds
When mature seeds were collected directly from fruits and air-dried (Fig. 3a), the periclinal wall of the outer layer shrank inwards, which resulted in a concaved surface and reticulated pattern of seed coat (Fig. 3c). For mature seeds from bird faeces (Fig. 3b), the surface of seed coat was eroded, and a number of cracks was observed (Fig. 3d).
Changes in seed viability and germinability after consumption by birds
To investigate whether the seeds could survive after consumption by birds, we fed the fruits to birds and collected seeds from faeces for viability testing and asymbiotic germination experiments. For the N. singapureana seeds collected from faeces, the mean viability was 35.6 ± 4.8% by the TTC stainability test, which was similar to the viability from intact fruits (32.4 ± 8.3%). However, no viable seeds of N. veratrifolia were found after consumption by birds (Table 3). Because no seed of N. veratrifolia was viable after consumption by birds, we only performed the asymbiotic germination experiments in N. singapureana seeds. The seeds collected from faeces had better germination percentage than those from intact fruits (Table 4). By 90 days of culture on 1/4 MS medium, most embryos were still enveloped by the seed coat (Fig. 4a); only a few seeds had become swollen and protruded from the seed coat (Fig. 4a). After germination, the young protocorm enlarged and developed into a small rhizome-like structure (Fig. 4b).
Animal-dispersed fleshy fruits are rare in Orchidaceae because most orchid species have capsules that become dry and dehiscent to disperse numerous seeds by wind (Arditti and Ghani 2000). Orchid species with fleshy fruits are primarily observed in the early diverging subfamilies, e.g. Apostasia and Neuwiedia (subfamily Apostasioideae), Selenipedium (subfamily Cypripedioideae), and Cyrtosia and Vanilla (subfamily Vanilloideae) (Nakamura and Hamada 1978; Dressler 1989; Clements and Molvray 1999). Whereas species with fleshy fruits are not found in the subfamily Orchidoideae, and only Yoania is confirmed to produce fleshy fruits in the subfamily Epidendroideae (Suetsugu 2018a,b). Mapping of the traits of fleshy or capsular fruits on a phylogenetic tree based on molecular data (Cameron et al. 1999) suggests that species in the subfamily Apostasioideae have fleshy fruits as a basal character (Additional file 1: Fig. S1). In the subfamily Apostasioideae, only two Neuwiedia species, i.e. N. griffithii and N. veratrifolia are known to possess capsular fruits (Kocyan and Endress 2001). Such an observation would suggest that fleshy fruit might be a plesiomorphic character in Orchidaceae, and the production of fleshy fruits arose a few times in other orchid subfamilies. In monocots and dicots, animal-dispersed fleshy fruits should undergo concerted convergence in association with colonization of a shady environment and have evolved repeatedly (Smith 2001; Givnish et al. 2005). Indeed, up to 95% of the woody understory species in neotropical rain forests bear fleshy fruits (Gentry 1982). Some orchids with fleshy fruits are fully mycoheterotrophic plants; examples are Cyrtosia and Yoania, inhabiting dark understory habitats with less wind (Suetsugu et al 2015; Suetsugu 2018a,b). Although N. singapureana is a green orchid species inhabiting the tropical forest understory, seed dispersal by animals should be an effective way for long-distance dispersal under closed canopies. Recently, A. nipponica is found to obtain most of its carbon resource from mycorrhizal association (Suetsugu and Matsubayashi 2020). Partial mycoheterotrophy might be another factor for Apostasioid species to thrive in dark understory habitats. A further study on the seed dispersal systems of five subfamilies using phylogenetic reconstruction of ancestral character states would provide insights into the evolution of seed dispersal system in Orchidaceae.
In this study, birds were confirmed to be the primary dispersers of N. singapureana seeds in the understory of tropical forests in China (Fig. 1f; Additional file 2: Video S1). So far, only a fully mycoheterotrophic orchid, Cyrtosia septentrionalis was reported to adapt avian endozoochory in the understory of temperate forests in Japan (Suetsugu et al. 2015). Both orchid species have fleshy fruits that turn red in autumn. It has been reported that birds may use color to discover and identify fruits (Wheelwright and Janson 1985). The most conspicuous colors of fleshy fruit to attract birds are red and black, and nearly all birds avoid green fruits (Duan et al. 2014). In Apostasia and Yoania, their fruits eaten by crickets and camel crickets display green and pinkish white respectively (Suetsugu 2018b, 2020). In N. singapureana and C. septentrionalis, the selection by birds for increased fruit attractiveness may raise investment in energy in producing the color display, such as carotenoid biosynthesis. It is also notable that fleshy fruits of Apostasia and Yoania at the ground level have to associated with endozoochory by terrestrial invertebrates (2018a, b and 2020). While both C. septentrionalis (Suetsugu et al. 2015) and N. singapureana possess the robust stem as a perch that facilitates fleshy fruit consumption by birds. Within the subfamily Apotasioideae, the occurrence of different strength and length of stem types may be a morphological adaptation to dissimilar seed disperser.
It is noteworthy that the indehiscent, fleshy fruit is regularly accompanied with hard, crustose seed coats in Orchidaceae (Nishimura and Tamura 1993; Clements and Molvray 1999; Yang and Lee 2014). In this study, greenish-blue staining with TBO in the thickened wall of the seed coat of N. singapureana indicated the accumulation of lignin in the coat wall. Furthermore, the lignified seed coat was much thicker for N. singapureana than N. veratrifolia (Fig. 2), the wind-dispersed sister species. The thickened lignified seed coat also occurred in orchids with fleshy fruits, such as Cyrtosia (Yang and Lee 2014; Suetsugu et al. 2015) and Yoania (Suetsugu 2018a,b), which suggests an adaptive trait of seed development. After passing through the digestive tracts of birds, most seeds of N. singapureana remained alive. However, no viable seeds of N. veratrifolia were detected after passing through the digestive tracts of birds (Table 3). The heavily lignified seed coat may protect the seeds as they pass through the digestive tracts of birds.
Seeds of N. singapureana are ellipsoid to ovoid in shape rather than the linear seeds in the dehiscent capsule of its sister species N. veratrifolia (Barsberg et al. 2018). Furthermore, the embryo is much larger for N. singapureana than its sister species N. veratrifolia (Fig. 2). Such enlarged embryo in Orchidaceae was reported for seeds of fleshy fruits (i.e., Cyrtosia [Yang and Lee 2014] and Yoania [Suetsugu 2018b]). In orchids, the seed morphology, or embryo size, may be related to the different lifestyles. In Liparis, the larger embryo of epiphytic L. fujisanensis has more cells than the smaller embryo of terrestrial L. koreana and L. kumokiri, but their cell size does not considerably differ (Tsutsumi et al. 2007). Moreover, the embryo cells are larger for N. singapureana than its sister species N. veratrifolia. Whether the morphological traits of seeds are related to the evolution of fleshy fruits remains to be analysed.
The feeding treatment resulted in several cracks and removed the wall covering on the seed coat of orchids (Fig. 3). The germination percentage increased significantly after the feeding treatment as compared with seeds from intact fruits (Table 4), which suggests that the dormancy was broken by the digestive tract. In Yoania japonica, higher germination was observed in seeds defecated by camel crickets than in seeds collected directly from fruits (Suetsugu 2018b). Thick seed coats of many species are responsible for restricting the diffusion of water, nutrients and oxygen to the embryo (Simpson 1990; Corbineau and Come 1995). Passage through digestive systems of animals can scarify the seed coat and thus improve germination, especially for seeds with a hard seed coat (Howe and Smallwood 1982). Similar mechanisms may also be involved in this orchid dispersal system. The increase in the exchange of materials across the seed coat may lead to the release of dormancy. Thus, under the natural condition, seed dispersal by birds may have facilitated the subsequent germination and colonization of N. singapureana.
In this study, birds were the primary dispersers of N. singapureana seeds. As the fruits matured, they turned from green to red, then the birds started to eat the red fruits. After passing through the digestive tracts of birds, the seeds still stay alive, and the walls of the seed coat contain several cracks. The germination percentage increased significantly for digested seeds as compared with intact fruit seeds. The thickened and lignified seed coat may protect seeds as they pass through the digestive tracts of birds. The animal-mediated seed dispersal strategy may be an adaptive mechanism promoting the success of colonization in dark understory habitats.
Availability of data and materials
Arditti J (1992) Fundamentals of orchid biology. John Wiley and Sons Inc, New York
Arditti J, Ghani AKA (2000) Numerical and physical properties of orchid seeds and their biological implications. New Phytol 145:367–421
Barsberg ST, Lee YI, Rasmussen HN (2018) Development of C-lignin with G/S-lignin and lipids in orchid seed coats - an unexpected diversity exposed by ATR-FT-IR spectroscopy. Seed Sci Res 28:41–51
Cameron KM, Chase MW, Whitten M, Kores P, Jarrell O, Albert V, Yukawa T, Hills H, Goldman D (1999) A phylogenetic analysis of the Orchidaceae: evidence from rbcL nucleotide sequences. Amer J Bot 86:208–224
Clements MA (1999) Embryology. In: Pridgeon AM, Cribb PJ, Chase MW, Rasmussen FN (eds) Genera Orchidacearum, vol 1. general introduction, Apostasioideae. Cypripedioideae. Oxford University Press, Oxford, pp 38–58
Clements MA, Molvray M (1999) Seed morphology. In: Pridgeon AM, Cribb PJ, Chase MW, Rasmussen FN (eds) Genera Orchidacearum, vol 1. general introduction, Apostasioideae. Cypripedioideae. Oxford University Press, Oxford, pp 59–66
Corbineau F, Come D (1995) Control of seed germination and dormancy by the gaseous environment. In: Kigel J, Galili G (eds) Seed development and germination. Marcel Dekker, New York, pp 397–424
Dressler RL (1989) The improbable Selenipedium chica. Amer Orchid Soc Bull 58:549–552
Dressler RL (1993) Phylogeny and classification of the orchid family. Dioscorides Press, Portland
Duan Q, Goodale E, Quan RC (2014) Bird fruit preferences match the frequency of fruit colours in tropical Asia. Sci Rep 4:5627
Eriksson O (2000) Seed dispersal and colonization ability of plants—assessment and implications for conservation. Folia Geobotanica 35:115–123
Gentry AH (1982) Patterns of neotropical plant species diversity. Evol Biol 15:1–84
Givnish TJ, Pires JC, Graham SW, McPherson MA, Prince LM, Patterson TB et al (2005) Repeated evolution of net venation and fleshy fruits among monocots in shaded habitats confirms a priori predictions: evidence from an ndhF phylogeny. Proc R Soc Lond B 272:1481–1490
Howe HF, Smallwood J (1982) Ecology of seed dispersal. Annu Rev Ecol Systemat 13:201–228
Kocyan A, Endress PK (2001) Floral structure and development of Apostasia and Neuwiedia (Apostasioideae) and their relationships to other Orchidaceae. Int J Plant Sci 162:847–867
Lee YI, Lee N, Yeung CE, Chung MC (2005) Embryo development of Cypripedium formosanum in relation to seed germination in vitro. J Am Soc Hortic Sci 130:747–753
Murashige T, Skoog F (1962) A revised medium for rapid growth and bioassays with tabacco tissue culture. Physiol Plant 15:473–497
Nakamura SI, Hamada M (1978) On the seed dispersal of an achlorophyllous orchid Galeola septentrionalis. J Jpn Bot 53:260–263
Nishimura G, Tamura M (1993) Seed coat formation in Apostasia nipponica. J Jap Bot 68:219–223
Simpson GM (1990) Seed dormancy in grasses. Cambridge University Press Cambridge, UK
Smith JF (2001) High species diversity in fleshy-fruited tropical understory plants. Amer Nat 157:646–653
Suetsugu K (2018a) Independent recruitment of a novel seed dispersal system by camel crickets in achlorophyllous plants. New Phytol 217:828–835
Suetsugu K (2018b) Seed dispersal in the mycoheterotrophic orchid Yoania japonica: further evidence for endozoochory by camel crickets. Plant Biol 20:707–712
Suetsugu K (2020) A novel seed dispersal mode of Apostasia nipponica could provide some clues to the early evolution of the seed dispersal system in Orchidaceae. Evol Lett. https://doi.org/10.1002/evl3.188
Suetsugu K, Matsubayashi J (2020) Evidence for mycorrhizal cheating in Apostasia nipponica, an early-diverging member of the Orchidaceae. New Phytol. https://doi.org/10.1111/nph.17049
Suetsugu K, Kawakita A, Kato M (2015) Avian seed dispersal in a mycoheterotrophic orchid Cyrtosia septentrionalis. Nat Plants 1:15052
Tsutsumi C, Yukawa T, Lee NS, Lee CS, Kato M (2007) Phylogeny and comparative seed morphology of epiphytic and terrestrial species of Liparis (Orchidaceae) in Japan. J Plant Res 120:405–412
Wheelwright NT, Janson CH (1985) Colors of fruit displays of bird-dispersed plants in two tropical forests. Am Nat 126:777–799
World Checklist of Monocotyledons (2006) The Board of Trustees of the Royal Botanic Gardens, Kew. http://www.kew.org/wcsp/monocots/. Accessed 8 May 2009.
Yang CK, Lee YI (2014) The seed development of a mycoheterotrophic orchid Cyrtosia javanica. Blume Bot Stud 55:44
Yeung EC, Chan CKW (2015) The glycol methacrylate embedding resins-Technovit 7100 and 8100. Plant microtechniques and protocols. Springer, Berlin, pp 67–82
This work was supported by the grants from the Beijing Municipal Administration Center of Parks (ZX2016010), China to Yu Zhang. The funders had no role in the design of the study; collection, analyses, or interpretation of data; writing of the manuscript, or decision to publish.
Ethics approval and consent to participate
Consent for publication
The authors declare that they have no competing interests.
Springer Nature remains neutral with regard to jurisdictional claims in published maps and institutional affiliations.
About this article
Cite this article
Zhang, Y., Li, YY., Wang, M. et al. Seed dispersal in Neuwiedia singapureana: novel evidence for avian endozoochory in the earliest diverging clade in Orchidaceae. Bot Stud 62, 3 (2021). https://doi.org/10.1186/s40529-020-00308-z
